DRC-48V100W1RZ - Delta 1.92A 48V DIN Rail Power Supply
Technical Specifications of Delta DRC-48V100W1RZ 1.92A 48V DIN Rail Power Supply
| Brand | Delta |
| Product Type | SMPS |
| Product | DRC-48V100W1RZ |
Delta 1.92A 48V DIN Rail Power Supply DRC-48V100W1RZ Technical Specifications:
| Specification | Value |
|---|---|
| Output Current | 1.92A |
| Output Voltage | 48V |
| Output Voltage Adjustment Range | 43.2-55 Vdc |
| Output Power | 92.16W |
| Line Regulation | ± 0.5% @ 115 Vac & 230 Vac |
| Load Regulation | ± 0.5% |
| PARD | < 150 mVpp @ 0°C to +70°C < 450 mVpp @ -30°C to 0°C |
| Start-up Time | 300 ms typ. @ 115 Vac & 230 Vac |
| Hold-up Time | 12 ms typ. @ 115 Vac & 60 ms typ. 230 Vac (100% load) |
| Dynamic Response (Overshoot & Undershoot O/P Voltage) | ± 10% @ 115 Vac & 230 Vac input, 10-100% load (Slew Rate: 2.5 A/μS, 50% duty cycle @ 5 Hz & 10 kHz) |
| Start-up with Capacitive Loads | 3,000 µF Max |
| Rise Time | 30 ms typ. @ 115 Vac & 230 Vac |
| Nominal Input Voltage | 100-240 Vac |
| Input Voltage Range | 85-264 Vac |
| Nominal Input Frequency | 50-60 Hz |
| Input Frequency Range | 47-63Hz |
| Input Current | < 1.8A @ 115 Vac < 1.2A @ 230 Vac |
| Efficiency at 100% load | 89.0% typ. @ 115 Vac 91.5% typ. @ 230 Vac |
| Inrush Current | 70 A typ. @ 230 Vac |
| Leakage Current | < 0.25 mA @ 240 Vac |
| Power Dissipation | 0% load: 0.21 W typ. @ 115 Vac & 230 Vac |
| Case Chassis / Cover | Plastic |
| Indicator | Green LED DC OK |
| Cooling System | Convection |
| Input Terminal | M2.5 x 2 Pins (Rated 300 V / 16 A) |
| Output Terminal | M2.5 x 4 Pins (Rated 300 V / 16 A) |
| Noise Sound Pressure Level (SPL) | < 25 dBA |
| Mounting Rail | Standard TS35 DIN Rail in accordance with EN 60715 |
| Wire | Input: AWG 24-12 Output: AWG 18-12 |
| Unit Weight | 0.23 kg (0.51 lb) |
| Vibration (Operating) | IEC 60068-2-6, Sine Wave: 10 Hz to 500 Hz @ 2 G; 10 min per cycle, 60 min for X, Y, Z direction |
| Operating Temperature | -30°C to +70°C (-40°C Cold Start) |
| Storage Temperature | -40°C to +85°C |
| Power De-rating | Temperature: > 50°C de-rate power by 2% / °C Input Voltage: < 100Vac de-rate power by 1% / Vac |
| Operating Humidity | 5 to 95% RH (Non-Condensing) |
| Shock Test (Non-Operating) | IEC 60068-2-27, Half Sine Wave: 50 G for duration of 11 ms; 3 times per direction |
| Operating Altitude | 0 to 5,000 Meters (6,560 ft) |
| Pollution Degree | 2 |
| Over Voltage Category | II (Compliance to EN 62477-1 OVC III with 2,000 Meters altitude) |
Call us for Delta 1.92A 48V DIN Rail Power Supply DRC-48V100W1RZ at the best rates. Technical Attributes of DRC-48V100W1RZ are 1.92A Output Current, 48V Output Voltage, 92.16W Output Power at competitive prices. It operates with a nominal input voltage of 100-240 Vac and supports an input voltage range of 85-264 Vac. The power supply covers a nominal input frequency of 50-60 Hz, with a broader input frequency range of 47-63Hz. With an input current of < 1.8A @ 115 Vac < 1.2A @ 230 Vac, it ensures efficient performance. The unit features a Green LED DC OK indicator, aiding in quick status checks. Both input and output terminals have M2.5 x 2 Pins (Rated 300 V / 16 A) and M2.5 x 4 Pins (Rated 300 V / 16 A) for secure connections. Designed for extreme environments, it Operating Temperature from -30°C to +70°C (-40°C Cold Start) and has a storage temperature of -40°C to +85°C. Unlock Exclusive Pricing with a Quote for your requirement of 1.92A 48V DIN Rail Power Supply. Trust in our ability to provide more advantageous pricing and dedicated support beyond other other Dealers.
