Delta DRC-24V30W1AG 1.25A 24V 30W DIN Rail Power Supply
The Delta DRC-24V30W1AG is a precise 1.25A 24V DIN Rail Power Supply engineered for industrial automation and small-scale control systems that require stable 24V DC output. It operates with a nominal input voltage of 100-240Vac and supports a wide input range of 90-264Vac at 50-60Hz. Manufactured by Delta industrial automation products, this model is part of the Delta power supply solutions and the DIN Rail CHROME Series, ensuring reliable performance in compact control panels and low-power automation applications.
| Output Current | Delta |
| Product Type | SMPS |
| Product | DRC-24V30W1AG |
Delta 1.25A 24V DIN Rail Power Supply DRC-24V30W1AG Technical Specifications:
| Specification | Value |
|---|---|
| Output Current | 1.25A |
| Output Voltage | 24V |
| Output Voltage Adjustment Range | 23.52-24.48Vdc |
| Output Power | 30W |
| Line Regulation | < 0.5% (@ 90-264Vac input, 100% load) |
| Load Regulation | < 1.0% (@ 90-264Vac input, 0-100% load) |
| PARD | < 100mVpp |
| Start-up Time | < 2,000ms @ nominal input (100% load) |
| Hold-up Time | > 25ms @ 115Vac, > 60ms @ 230Vac (100% load) |
| Dynamic Response (Overshoot & Undershoot O/P Voltage) | ± 5% @ 90-264Vac input, 10-100% load (Slew Rate: 0.1A/μs, 50% duty cycle @ 5Hz to 100Hz) |
| Start-up with Capacitive Loads | 3,000µF Max |
| Rise Time | < 70ms @ nominal input (100% load) |
| Nominal Input Voltage | 100-240Vac |
| Input Voltage Range | 90-264Vac |
| Nominal Input Frequency | 50-60Hz |
| Input Frequency Range | 47-63Hz |
| DC Input Voltage Range | 125-375Vdc |
| Input Current | < 0.80A @ 115Vac, < 0.60A @ 230Vac |
| Efficiency at 100% load | > 87.0% @ 115Vac & 230Vac |
| Inrush Current | < 25A @ 115Vac, < 50A @ 230Vac |
| Leakage Current | < 0.25mA @ 240Vac |
| Power Dissipation | 0% load: < 0.3W @ 115Vac & 230Vac 100% load: < 4.48W @ 115Vac & 230Vac |
| Case Chassis / Cover | Plastic |
| Indicator | Green LED (DC OK) |
| Cooling System | Convection |
| Input Terminal | 2 Pins (Rated 300V/25A) |
| Output Terminal | 4 Pins (Rated 300V/25A) |
| Noise Sound Pressure Level (SPL) | < 25dBA |
| Mounting Rail | Standard TS35 DIN Rail in accordance with EN 60715 |
| Wire | Input / Output: AWG 24-12 |
| Unit Weight | 0.14 kg (0.31 lb) |
| Vibration (Operating) | IEC 60068-2-6, Sine Wave: 10-500Hz @ 19.6m/S² (2G peak); 10 min per cycle, 60 min for all X, Y, Z directions |
| Shock Test (Operating) | IEC 60068-2-27, Half Sine Wave: 4G for a duration of 22ms, 3 shocks for each 3 directions, 9 times in total |
| Operating Temperature | -25°C to +71°C |
| Storage Temperature | -25°C to +85°C |
| Power De-rating | > 55°C de-rate power by 2.5% / °C |
| Operating Humidity | 5 to 95% RH (Non-Condensing) |
| Operating Altitude | 0 to 2,000 Meters (6,560 ft.) |
| Pollution Degree | 2 |
| Over Voltage Category | II |
The Delta DRC-24V30W1AG is suitable for compact industrial control cabinets, sensor modules, and small automation devices requiring a consistent 24V DC output. Its DIN rail design allows organized installation, and the Green LED DC OK indicator provides instant verification of operational status, simplifying monitoring and maintenance tasks.
Built for challenging industrial environments, this 1.25A 24V DIN Rail Power Supply operates reliably across temperatures from -25°C to +71°C, with storage support from -25°C to +85°C. Its robust design ensures stable output under fluctuating load conditions, making it ideal for process control, monitoring equipment, and other applications that demand uninterrupted low-current DC supply.
For organizations seeking a dependable, compact DIN rail power solution, the Delta DRC-24V30W1AG delivers operational stability and energy efficiency. Request a quote today to access competitive pricing and dedicated support, ensuring seamless integration and reliable 24V DC power delivery for your small-scale industrial automation systems.
