Contrinex YBB-14K4-0150-G012 Safety Sensor
The Contrinex YBB-14K4-0150-G012 Safety Sensors offers 24 supply voltage, 42 x 48 (standard) housing size, Light curtain basic standard product range, 251 mm sensor height. Manufactured by Contrinex under the Contrinex Safety Sensors category, this model belongs to the Contrinex YRB Series.
| Brand | Contrinex |
| Product Type | Safety Sensors |
| Model Number | YBB-14K4-0150-G012 |
Contrinex YBB-14K4-0150-G012 Safety Sensor – Technical Specifications
| Specification | Value |
|---|---|
| Supply voltage | 24 |
| Safety Level | Cat. 4, PL e, Type 4 |
| Housing size [mm] | 42 x 48 (standard) |
| Enclosure rating | IP 65 / IP 67 |
| Response time | 5.2 ms |
| Temperature range | -35...+60°C |
| Product Range | Light curtain basic standard |
| Sensor Height | 251 mm |
| Operating range | 0.25...3.5 m |
| Sender wavelength | IR 950 nm |
| Protective height | 142 mm |
| Polarity | PNP |
| Safety Type | Kit |
| Resolution | 14 mm (finger) |
| Beam gap | 8 mm |
