Contrinex DW-HD-613-M50-300 Inductive Sensor
The Contrinex DW-HD-613-M50-300 Inductive Sensors offers 25 mm operating range, 10...30 Supply voltage, Normally Open (NO) output, Silicone, 2 m, 3 wire Connection. Manufactured by Contrinex under the Contrinex Inductive Sensors category, this model belongs to the Contrinex DW Series.
| Brand | Contrinex |
| Product Type | Inductive Sensor |
| Model Number | DW-HD-613-M50-300 |
Contrinex DW-HD-613-M50-300 Inductive Sensor โ Technical Specifications
| Specification | Value |
|---|---|
| Operating range | 25 mm |
| Switching frequency max. | 100 Hz |
| Supply voltage | 10...30 |
| Polarity | PNP |
| Output | Normally Open (NO) |
| Connection | Silicone, 2 m, 3 wire |
| Housing size [mm] | M50 |
| Enclosure rating | IP 67 |
| Housing material | Stainless-steel V2A |
| Temperature range | 0...+180ยฐC |
| Sensor Height | 76 mm |
| Mounting | Non-embeddable |
| Interface | Standard output |
