PS3011-4820-0000 - Beckhoff Power Supply
Technical Specifications of Beckhoff Power Supply PS3011-4820-0000:
| Brand | Beckhoff |
| Product Type | Power Supply |
| Product | PS3011-4820-0000 |
PS3011-4820-0000 Beckhoff Power Supply Technical Specifications
| Specification | Value |
|---|---|
| Input voltage | AC 100...240 V, DC 110...150 V |
| Wide-range input | yes |
| Input current | typ. 4.5 A at 230 V AC |
| Switch-on current limiter | yes |
| Mains frequency | 50..60 Hz |
| Starting current | typ. 11 A peak at 230 V AC |
| Output voltage | 48 V DC |
| Adjustment range | 48...56 V DC |
| Output current | 20 A |
| Output | 960Â W |
| Efficiency | approx. 95% |
| Operating temperature | -25...+70°C |
| Shock resistance | conforms to EN 60068-2-27 |
| Vibration resistance | conforms to EN 60068-2-6 |
| Weight | approx. 1900 g |
| Approvals/markings | CE, UL508, DNV |
| Protection rating | IP20 |
| Housing - Dimensions (W x H x D) | 125 mm x 124 mm x 127 mm |
| Housing - Material | aluminum |
| Housing - Installation | on 35 mm DIN rail, conforming to EN 60715 with lock |
| Housing - Wiring | input/output: screw type connection,signal contact: spring-loaded technique |
| Housing - Connection cross-section | input:e*: 0.5â¦6 mm²,f*: 0.5â¦4 mm²,a*: 0.5â¦4 mm²output:e*: 0.5â¦16 mm²,f*: 0.5â¦10 mm²,a*: 0.5â¦10 mm²signal contact:e*: 0.15â¦1.5 mm²,f*: 0.15â¦1.5 mm²,a*: 0.15â¦1.5 mm² |
| Housing - Connection cross-section AWG | Input: AWG20-10Output: AWG22-8Signal contact: AWG26-14 |
| Housing - Stripping length | input: 7Â mm,output: 12 mm,signal contact: 7Â mm |
| Harmonic correction (PFC) | active |
| Extra power | 50%/4 s |
| Precise fuse release | yes |
| Outpout power for 4 s | 1440 W |
| Overload LED | yes |
| Shut down contact | yes |
