KM3702 - Beckhoff Bus Terminal Analog Input
KM3702 Beckhoff Bus Terminal Analog Input Technical Specifications
| Brand | Beckhoff |
| Product Type | Bus Terminal Analog Input |
| Product | KM3702 |
KM3702 Beckhoff Bus Terminal Analog Input Technical Specifications
| Specification | Value |
|---|---|
| Number of inputs | 2 |
| Current consumption K-bus | typ. 15 mA |
| Bit width in the process image | 2 x 3 byte input/output |
| Weight | approx. 100 g |
| Operating temperature | 0...55°C |
| Storage temperature | -25...+85°C |
| Relative humidity | 95%, no condensation |
| Vibration/shock resistance | conforms to EN 60068-2-6/EN 60068-2-27 |
| EMC immunity/emission | conforms to EN 61000-6-2/EN 61000-6-4 |
| Protect. rating/installation pos. | IP20/variable |
| Approvals/markings | CE, UL |
| Housing - Design form | compact terminal housing with signal LEDs |
| Housing - Material | polycarbonate |
| Housing - Dimensions (W x H x D) | 24 mm x 100 mm x 52 mm |
| Housing - Installation | on 35 mm DIN rail, conforming to EN 60715 with lock |
| Housing - Side by side mounting by means of | double slot and key connection |
| Housing - Marking | â |
| Housing - Wiring | specific push-in connection |
| Current consumption power contacts | â (no power contacts) |
| Resolution | 1 hPa (1 mbar) per digit |
| Technology | relative pressure measurement |
