KM2652 - Beckhoff Bus Terminal Digital Output
KM2652 Beckhoff Bus Terminal Digital Output Technical Specifications
| Brand | Beckhoff |
| Product Type | Bus Terminal Digital Output |
| Product | KM2652 |
KM2652 Beckhoff Bus Terminal Digital Output Technical Specifications
| Specification | Value |
|---|---|
| Nominal voltage | 230 V AC (max. switching voltage 250 V AC) |
| Current consumption K-bus | typ. 130 mA |
| Bit width in the process image | 4 inputs (status hand, auto, relay ON/OFF), 2 outputs |
| Configuration | no address or configuration setting |
| Weight | approx. 110 g |
| Operating temperature | 0...55°C |
| Storage temperature | -25...+85°C |
| Relative humidity | 95%, no condensation |
| Vibration/shock resistance | conforms to EN 60068-2-6/EN 60068-2-27 |
| EMC immunity/emission | conforms to EN 61000-6-2/EN 61000-6-4 |
| Protect. rating/installation pos. | IP20/variable |
| Approvals/markings | CE |
| Housing - Design form | compact terminal housing with signal LEDs |
| Housing - Material | polycarbonate |
| Housing - Dimensions (W x H x D) | 24 mm x 100 mm x 52 mm |
| Housing - Installation | on 35 mm DIN rail, conforming to EN 60715 with lock |
| Housing - Side by side mounting by means of | double slot and key connection |
| Housing - Marking | â |
| Housing - Wiring | specific push-in connection |
| Current consumption power contacts | â |
| Special features | manual/automatic operation, switch setting readable |
| Max. output current | 6 A per channel |
| Load type | ohmic, inductive, lamp load |
| Number of outputs | 2 x change-over |
