KM2614 - Beckhoff Bus Terminal Digital Output
KM2614 Beckhoff Bus Terminal Digital Output Technical Specifications
| Brand | Beckhoff |
| Product Type | Bus Terminal Digital Output |
| Product | KM2614 |
KM2614 Beckhoff Bus Terminal Digital Output Technical Specifications
| Specification | Value |
|---|---|
| Nominal voltage | 230 V AC (max. switching voltage 250 V AC/30 V DC) |
| Current consumption K-bus | typ. 15 mA |
| Bit width in the process image | 4 outputs |
| Configuration | no address or configuration setting |
| Weight | approx. 250 g |
| Operating temperature | 0...55°C |
| Storage temperature | -25...+85°C |
| Relative humidity | 95%, no condensation |
| Vibration/shock resistance | conforms to EN 60068-2-6/EN 60068-2-27 |
| EMC immunity/emission | conforms to EN 61000-6-2/EN 61000-6-4 |
| Protect. rating/installation pos. | IP20/variable |
| Approvals/markings | CE |
| Current consumption power contacts | â |
| Special features | automatic/manual operation at the relay |
| Max. output current | 16 A |
| Load type | ohmic, inductive, lamp load |
| Number of outputs | 4 x change-over |
