KL9210 - Beckhoff Bus Terminals System
KL9210 Beckhoff Bus Terminals System Technical Specifications
| Brand | Beckhoff |
| Product Type | Bus Terminals System |
| Product | KL9210 |
KL9210 Beckhoff Bus Terminals System Technical Specifications
| Specification | Value |
|---|---|
| Nominal voltage | 24 V DC |
| Current consumption K-bus | typ. 10 mA |
| Bit width in the process image | 2 |
| Weight | approx. 55 g |
| Operating temperature | -25...+60°C |
| Storage temperature | -40..+85°C |
| Approvals/markings | CE, CCC, UL, ATEX, IECEx, DNV GL |
| Ex marking | ATEX:II 3 G Ex ec IIC T4 GcIECEx:Ex ec IIC T4 Gc |
| Housing - Design form | compact terminal housing with signal LEDs |
| Housing - Material | polycarbonate |
| Housing - Dimensions (W x H x D) | 12Â mm x 100Â mm x 70 mm |
| Housing - Installation | on 35 mm DIN rail, conforming to EN 60715 with lock |
| Housing - Side by side mounting by means of | double slot and key connection |
| Housing - Marking | labeling of the BZxxxx series |
| Housing - Wiring | solid conductor (s), flexible conductor (st) and ferrule (f): spring actuation by screwdriver |
| Housing - Connection cross-section | s*: 0.08...2.5 mm²,st*: 0.08...2.5 mm²,f*: 0.14...1.5 mm² |
| Housing - Connection cross-section AWG | s*: AWG28...14,st*: AWG28...14,f*: AWG26...16 |
| Housing - Stripping length | 8...9 mm |
| Housing - Current load power contacts | Imax: 10 A |
| Special features | integrated fuse |
