KL9070 - Beckhoff Bus Terminals System
KL9070 Beckhoff Bus Terminals System Technical Specifications
| Brand | Beckhoff |
| Product Type | Bus Terminals System |
| Product | KL9070 |
KL9070 Beckhoff Bus Terminals System Technical Specifications
| Specification | Value |
|---|---|
| Nominal voltage | รขยยค 60 V |
| Weight | approx. 50 g |
| Operating temperature | 0...55ยฐC |
| Storage temperature | -25...+85ยฐC |
| Approvals/markings | CE, CCC, UL, ATEX, IECEx |
| Ex marking | ATEX:II 3 G Ex ec IIC T4 GcIECEx:Ex ec IIC T4 Gc |
| Housing - Design form | compact terminal housing with signal LEDs |
| Housing - Material | polycarbonate |
| Housing - Dimensions (W x H x D) | 12ร mm x 100ร mm x 68 mm |
| Housing - Installation | on 35 mm DIN rail, conforming to EN 60715 with lock |
| Housing - Side by side mounting by means of | double slot and key connection |
| Housing - Marking | labeling of the BZxxxx series |
| Housing - Wiring | solid conductor (s), flexible conductor (st) and ferrule (f): spring actuation by screwdriver |
| Housing - Connection cross-section | s*: 0.08...2.5 mmยฒ,st*: 0.08...2.5 mmยฒ,f*: 0.14...1.5 mmยฒ |
| Housing - Connection cross-section AWG | s*: AWG28...14,st*: AWG28...14,f*: AWG26...16 |
| Housing - Stripping length | 8...9 mm |
| Housing - Current load power contacts | Imax: 10 A |
| Special features | dissipation of EMC interference via large copper surfaces on the DIN rail |
