KL9050 - Beckhoff Bus Terminals System
KL9050 Beckhoff Bus Terminals System Technical Specifications
| Brand | Beckhoff |
| Product Type | Bus Terminals System |
| Product | KL9050 |
KL9050 Beckhoff Bus Terminals System Technical Specifications
| Specification | Value |
|---|
| Nominal voltage | 24 V DC (-15%/+20%) |
| Input current | 70 mA + (total K-bus current)/4, 200 mA max. |
| Weight | approx. 75 g |
| Operating temperature | 0...55°C |
| Storage temperature | -25...+85°C |
| Relative humidity | 95%, no condensation |
| Vibration/shock resistance | conforms to EN 60068-2-6/EN 60068-2-27 |
| EMC immunity/emission | conforms to EN 61000-6-2/EN 61000-6-4 |
| Protect. rating/installation pos. | IP20/variable |
| Approvals/markings | CE, CCC, UL, ATEX, IECEx, DNV GL |
| Ex marking | ATEX:II 3 G Ex ec IIC T4 GcIECEx:Ex ec IIC T4 Gc |
| Special features | coupler terminal for K-bus extension (max. 64 Bus Terminals) |
