KL6301 - Beckhoff Bus Terminal Communication Interface

Name: Beckhoff KL6301
Brand: Beckhoff
SKU: KL6301
Rating: 4.7 (4 reviews)

KL6301 Beckhoff Bus Terminal Communication Interface Technical Specifications

Brand	Beckhoff
Product Type	Bus Terminal Communication Interface
Product	KL6301

KL6301 Beckhoff Bus Terminal Communication Interface Technical Specifications

Specification	Value
Nominal voltage	24 V DC (-15%/+20%)
Current consumption K-bus	typ. 55 mA
Bit width in the process image	input/output: 24 bytes
Configuration	TwinCAT (function blocks)
Weight	approx. 85 g
Operating temperature	0...55°C
Storage temperature	-25...+85°C
Relative humidity	95%, no condensation
Vibration/shock resistance	conforms to EN 60068-2-6/EN 60068-2-27
EMC immunity/emission	conforms to EN 61000-6-2/EN 61000-6-4
Protect. rating/installation pos.	IP20/variable
Approvals/markings	CE, CCC, UL, ATEX, IECEx
Ex marking	ATEX:II 3 G Ex ec IIC T4 GcIECEx:Ex ec IIC T4 Gc
Housing - Design form	compact terminal housing with signal LEDs
Housing - Material	polycarbonate
Housing - Dimensions (W x H x D)	12Â mm x 100Â mm x 68 mm
Housing - Installation	on 35 mm DIN rail, conforming to EN 60715 with lock
Housing - Side by side mounting by means of	double slot and key connection
Housing - Marking	labeling of the BZxxxx series
Housing - Wiring	solid conductor (s), flexible conductor (st) and ferrule (f): spring actuation by screwdriver
Housing - Connection cross-section	s: 0.08...2.5 mm²,st: 0.08...2.5 mm²,f*: 0.14...1.5 mm²
Housing - Connection cross-section AWG	s: AWG28...14,st: AWG28...14,f*: AWG26...16
Housing - Stripping length	8...9 mm
Housing - Current load power contacts	Imax: 10 A
Current consumption power contacts	â
Special features	TwinCAT library: TwinCAT PLC EIB
Number of channels	1
Technology	KNX/EIB
