KL5051 - Beckhoff Bus Terminals Position Measurement

Name: Beckhoff KL5051
Brand: Beckhoff
SKU: KL5051
Rating: 4.4 (4 reviews)

KL5051 Beckhoff Bus Terminals Position Measurement Technical Specifications

Brand	Beckhoff
Product Type	Bus Terminals Position Measurement
Product	KL5051

KL5051 Beckhoff Bus Terminals Position Measurement Technical Specifications

Specification	Value
Current consumption K-bus	typ. 75 mA
Bit width in the process image	input/output: 2 x 16 bit data, 2 x 8 bit control/status
Weight	approx. 80 g
Operating temperature	0...55°C
Storage temperature	-25...+85°C
Relative humidity	95%, no condensation
Vibration/shock resistance	conforms to EN 60068-2-6/EN 60068-2-27
EMC immunity/emission	conforms to EN 61000-6-2/EN 61000-6-4
Protect. rating/installation pos.	IP20/variable
Pluggable wiring	for all KSxxxx Bus Terminals
Approvals/markings	CE, CCC, UL, ATEX, IECEx
Ex marking	ATEX:II 3 G Ex ec IIC T4 GcIECEx:Ex ec IIC T4 Gc
Housing - Design form	compact terminal housing with signal LEDs
Housing - Material	polycarbonate
Housing - Dimensions (W x H x D)	12Â mm x 100Â mm x 68 mm
Housing - Installation	on 35 mm DIN rail, conforming to EN 60715 with lock
Housing - Side by side mounting by means of	double slot and key connection
Housing - Marking	labeling of the BZxxxx series
Housing - Wiring	solid conductor (s), flexible conductor (st) and ferrule (f): spring actuation by screwdriver
Housing - Connection cross-section	s: 0.08...2.5 mm²,st: 0.08...2.5 mm²,f*: 0.14...1.5 mm²
Housing - Connection cross-section AWG	s: AWG28...14,st: AWG28...14,f*: AWG26...16
Housing - Stripping length	8...9 mm
Housing - Current load power contacts	Imax: 10 A
Current consumption power contacts	no data
Special features	bidirectional
Number of channels	1 encoder interface
Technology	SSI encoder interface
