KL4132 - Beckhoff Bus Terminal Analog Output
KL4132 Beckhoff Bus Terminal Analog Output Technical Specifications
| Brand | Beckhoff |
| Product Type | Bus Terminal Analog Output |
| Product | KL4132 |
KL4132 Beckhoff Bus Terminal Analog Output Technical Specifications
| Specification | Value |
|---|
| Current consumption K-bus | typ. 75 mA |
| Bit width in the process image | output: 2 x 16Â bit data (2 x 8Â bit control/status optional) |
| Configuration | no address or configuration setting |
| Weight | approx. 85 g |
| Operating temperature | 0...55°C |
| Storage temperature | -25...+85°C |
| Relative humidity | 95%, no condensation |
| Vibration/shock resistance | conforms to EN 60068-2-6/EN 60068-2-27 |
| EMC immunity/emission | conforms to EN 61000-6-2/EN 61000-6-4 |
| Protect. rating/installation pos. | IP20/variable |
| Pluggable wiring | for all KSxxxx Bus Terminals |
| Approvals/markings | CE, CCC, UL, ATEX, IECEx |
| Ex marking | ATEX:II 3 G Ex ec IIC T4 GcIECEx:Ex ec IIC T4 Gc |
| Housing - Design form | compact terminal housing with signal LEDs |
| Housing - Material | polycarbonate |
| Housing - Dimensions (W x H x D) | 12Â mm x 100Â mm x 68 mm |
| Housing - Installation | on 35 mm DIN rail, conforming to EN 60715 with lock |
| Housing - Side by side mounting by means of | double slot and key connection |
| Housing - Marking | labeling of the BZxxxx series |
| Housing - Wiring | solid conductor (s), flexible conductor (st) and ferrule (f): spring actuation by screwdriver |
| Housing - Connection cross-section | s*: 0.08...2.5 mm²,st*: 0.08...2.5 mm²,f*: 0.14...1.5 mm² |
| Housing - Connection cross-section AWG | s*: AWG28...14,st*: AWG28...14,f*: AWG26...16 |
| Housing - Stripping length | 8...9 mm |
| Housing - Current load power contacts | Imax: 10 A |
| Current consumption power contacts | â (no power contacts) |
| Special features | increased resolution |
| Number of outputs | 2 |
| Resolution | 16 bit |
| Signal voltage | -10â¦+10 V |
| Technology | single-ended |
