KL3403 - Beckhoff Bus Terminal Analog Input

Name: Beckhoff KL3403
Brand: Beckhoff
SKU: KL3403
Rating: 4.6 (4 reviews)

KL3403 Beckhoff Bus Terminal Analog Input Technical Specifications

KL3403 Beckhoff Bus Terminal Analog Input Technical Specifications

Specification	Value
Number of inputs	3 x current, 3 x voltage
Current consumption K-bus	typ. 115 mA
Bit width in the process image	input/output: 3 x 16 bit data, 3 x 8 bit control/status
Weight	approx. 75 g
Operating temperature	-25...+60°C
Storage temperature	-40..+85°C
Relative humidity	95%, no condensation
Vibration/shock resistance	conforms to EN 60068-2-6/EN 60068-2-27
EMC immunity/emission	conforms to EN 61000-6-2/EN 61000-6-4
Protect. rating/installation pos.	IP20/variable
Pluggable wiring	for all KSxxxx Bus Terminals
Approvals/markings	CE, UL
Housing - Design form	compact terminal housing with signal LEDs
Housing - Material	polycarbonate
Housing - Dimensions (W x H x D)	12Â mm x 100Â mm x 68 mm
Housing - Installation	on 35 mm DIN rail, conforming to EN 60715 with lock
Housing - Side by side mounting by means of	double slot and key connection
Housing - Marking	labeling of the BZxxxx series
Housing - Wiring	solid conductor (s), flexible conductor (st) and ferrule (f): spring actuation by screwdriver
Housing - Connection cross-section	s: 0.08...2.5 mm²,st: 0.08...2.5 mm²,f*: 0.14...1.5 mm²
Housing - Connection cross-section AWG	s: AWG28...14,st: AWG28...14,f*: AWG26...16
Housing - Stripping length	8...9 mm
Housing - Current load power contacts	Imax: 10 A
Current consumption power contacts	â (no power contacts)
Special features	energy meter, power measurement, true RMS
Resolution	16 bit (21 bit, internal)
Technology	3-phase power measurement
