KL2872 - Beckhoff Bus Terminal Digital Output
KL2872 Beckhoff Bus Terminal Digital Output Technical Specifications
| Brand | Beckhoff |
| Product Type | Bus Terminal Digital Output |
| Product | KL2872 |
KL2872 Beckhoff Bus Terminal Digital Output Technical Specifications
| Specification | Value |
|---|---|
| Connection technology | flat-ribbon cable |
| Nominal voltage | 24 V DC (-15%/+20%) |
| Current consumption K-bus | typ. 5 mA |
| Bit width in the process image | 16 outputs |
| Configuration | no address or configuration setting |
| Weight | approx. 55 g |
| Operating temperature | 0...55°C |
| Storage temperature | -25...+85°C |
| Relative humidity | 95%, no condensation |
| Vibration/shock resistance | conforms to EN 60068-2-6/EN 60068-2-27 |
| EMC immunity/emission | conforms to EN 61000-6-2/EN 61000-6-4 |
| Protect. rating/installation pos. | IP20/variable |
| Approvals/markings | CE, CCC, UL, ATEX, IECEx |
| Ex marking | ATEX:II 3 G Ex ec IIC T4 GcIECEx:Ex ec IIC T4 Gc |
| Housing - Design form | compact terminal housing with signal LEDs |
| Housing - Material | polycarbonate |
| Housing - Dimensions (W x H x D) | 12 mm x 100 mm x 73 mm |
| Housing - Installation | on 35 mm DIN rail, conforming to EN 60715 with lock |
| Housing - Side by side mounting by means of | double slot and key connection |
| Housing - Marking | labeling of the BZxxxx series |
| Housing - Wiring | flat-ribbon cable connection |
| Housing - Connection cross-section | common flat-ribbon cables, AWG28, spacing 1.27 mm |
| Current consumption power contacts | typ. 60 mA from the supply |
| Special features | ideal for multi-pin connector valve terminals |
| Max. output current | 0.5 A (short-circuit proof) per channel |
| Load type | ohmic, inductive, lamp load |
| Number of outputs | 16 |
