KL2032 - Beckhoff Bus Terminal Digital Output
Beckhoff KL2032 Bus Terminal Digital Output offers dual 24V DC channels, ensuring reliable and efficient control in industrial automation systems.
| Brand | Beckhoff |
| Product Type | Bus Terminal Digital Output |
| Product | KL2032 |
KL2032 Beckhoff Bus Terminal Digital Output Technical Specifications
| Specification | Value |
|---|---|
| Connection technology | 4-wire |
| Nominal voltage | 24 V DC (-15%/+20%) |
| Current consumption K-bus | typ. 5 mA |
| Bit width in the process image | 2 outputs |
| Configuration | no address or configuration setting |
| Weight | approx. 55 g |
| Operating temperature | -25...+60°C |
| Storage temperature | -40..+85°C |
| Relative humidity | 95%, no condensation |
| Vibration/shock resistance | conforms to EN 60068-2-6/EN 60068-2-27 |
| EMC immunity/emission | conforms to EN 61000-6-2/EN 61000-6-4 |
| Protect. rating/installation pos. | IP20/variable |
| Pluggable wiring | for all KSxxxx Bus Terminals |
| Approvals/markings | CE, CCC, UL, ATEX, IECEx, DNV GL |
| Ex marking | ATEX:II 3 G Ex ec IIC T4 GcIECEx:Ex ec IIC T4 Gc |
| Housing - Design form | compact terminal housing with signal LEDs |
| Housing - Material | polycarbonate |
| Housing - Dimensions (W x H x D) | 12Â mm x 100Â mm x 68 mm |
| Housing - Installation | on 35 mm DIN rail, conforming to EN 60715 with lock |
| Housing - Side by side mounting by means of | double slot and key connection |
| Housing - Marking | labeling of the BZxxxx series |
| Housing - Wiring | solid conductor (s), flexible conductor (st) and ferrule (f): spring actuation by screwdriver |
| Housing - Connection cross-section | s*: 0.08...2.5 mm²,st*: 0.08...2.5 mm²,f*: 0.14...1.5 mm² |
| Housing - Connection cross-section AWG | s*: AWG28...14,st*: AWG28...14,f*: AWG26...16 |
| Housing - Stripping length | 8...9 mm |
| Housing - Current load power contacts | Imax: 10 A |
| Current consumption power contacts | typ. 20 mA + load |
| Max. output current | 0.5 A (short-circuit proof) per channel |
| Load type | ohmic, inductive, lamp load |
| Number of outputs | 2 |
The Beckhoff KL2032 Bus Terminal Digital Output is designed to provide stable and precise signal switching in automation environments. Operating at a 24 V DC nominal voltage, it delivers 2 independent outputs with a maximum 0.5 A per channel, each short-circuit proof for safety and reliability. With 4-wire connection technology and compatibility with KSxxxx Bus Terminals, it integrates seamlessly into modular control systems. The terminal consumes only typical 5 mA from the K-bus and 20 mA + load from power contacts, making it highly energy-efficient. Built within a compact 12 x 100 x 68 mm polycarbonate housing, it is easy to install on 35 mm DIN rails and includes signal LEDs for real-time diagnostics.
The KL2032 withstands operating temperatures from -25°C to +60°C and complies with EN 61000 EMC immunity standards, ensuring dependable operation in demanding factory conditions. Certified with CE, UL, ATEX, and IECEx, it meets global safety standards, while its IP20 rating protects against dust and accidental contact. Weighing just 55 g, the terminal is lightweight yet durable enough for long-term industrial use. Engineers can rely on this terminal for ohmic, inductive, and lamp load switching, making it versatile for diverse applications.
Applications of the KL2032 Digital Output Bus Terminal include packaging systems, conveyor automation, robotic handling, and process control panels. For junior engineers, the plug-and-play configuration with no addressing requirements makes it simple to use, while senior technicians value its fast response time, clear diagnostics, and rugged performance in continuous operations. Trusted worldwide, the Beckhoff KL2032 Bus Terminal Digital Output is a dependable solution for industries seeking efficiency, reliability, and easy integration.
