KL1212 - Beckhoff Bus Terminal Digital Input
KL1212 Beckhoff Bus Terminal Digital Input Technical Specifications
| Brand | Beckhoff |
| Product Type | Bus Terminal Digital Input |
| Product | KL1212 |
KL1212 Beckhoff Bus Terminal Digital Input Technical Specifications
| Specification | Value |
|---|---|
| Connection technology | 3-wire |
| Specification | EN 61131-2, type 1 |
| Number of inputs | 2 |
| Nominal voltage | 24 V DC (-15%/+20%) |
| "0" signal voltage | -3...+5 V |
| "1" signal voltage | 15...30 V |
| Input filter | typ. 3.0 ms |
| Input current | typ. 5 mA |
| Current consumption K-bus | typ. 8 mA |
| Bit width in the process image | input/output: 4 inputs (2 error bits/2 signal bits); 2 outputs (2 sensor supply) |
| Configuration | no address or configuration setting |
| Weight | approx. 55 g |
| Operating temperature | 0...55°C |
| Storage temperature | -25...+85°C |
| Relative humidity | 95%, no condensation |
| Vibration/shock resistance | conforms to EN 60068-2-6/EN 60068-2-27 |
| EMC immunity/emission | conforms to EN 61000-6-2/EN 61000-6-4 |
| Protect. rating/installation pos. | IP20/variable |
| Pluggable wiring | for all KSxxxx Bus Terminals |
| Approvals/markings | CE, CCC, UL, ATEX, IECEx, DNV GL |
| Ex marking | ATEX:II 3 G Ex ec IIC T4 GcIECEx:Ex ec IIC T4 Gc |
| Housing - Design form | compact terminal housing with signal LEDs |
| Housing - Material | polycarbonate |
| Housing - Dimensions (W x H x D) | 12Â mm x 100Â mm x 68 mm |
| Housing - Installation | on 35 mm DIN rail, conforming to EN 60715 with lock |
| Housing - Side by side mounting by means of | double slot and key connection |
| Housing - Marking | labeling of the BZxxxx series |
| Housing - Wiring | solid conductor (s), flexible conductor (st) and ferrule (f): spring actuation by screwdriver |
| Housing - Connection cross-section | s*: 0.08...2.5 mm²,st*: 0.08...2.5 mm²,f*: 0.14...1.5 mm² |
| Housing - Connection cross-section AWG | s*: AWG28...14,st*: AWG28...14,f*: AWG26...16 |
| Housing - Stripping length | 8...9 mm |
| Housing - Current load power contacts | Imax: 10 A |
| Sensor supply max. | 0.5 A (short-circuit-proof) |
| Input/output bit assignments | input: bit 3 bit 2 bit 1 bit 0 output: bit 1 bit 0err. 2 err. 1 on 2 on 1 off 2 off 1 |
