IP5009-B310 - Beckhoff Fieldbus Box And IO-Link Box

Name: Beckhoff IP5009-B310
Brand: Beckhoff
SKU: IP5009-B310
Rating: 4.4 (4 reviews)

Technical Specifications of Beckhoff Fieldbus Box And IO-Link Box IP5009-B310:

IP5009-B310 Beckhoff Fieldbus Box And IO-Link Box Technical Specifications

Specification	Value
Number of channels	1
Sensor supply	from control voltage, max. 0.5 A, short-circuit proof in total
Power supply connection	feed: 1 x M8 male socket, 4-pin, a-coded; downstream connection: 1 x M8 female socket, 4-pin, a-coded
Bit width in the process image	input: 1 x 32 bit data (1 x 8 bit control/status optional)
Electrical isolation	depends on the bus system
Configuration possibility	via KS2000 or the controller, DP-V1 extensions are supported
Data transfer rates	automatic detection up to 12 Mbaud
Bus interface	1 x M12 socket, 5-pin, B-coded
Data transfer medium	shielded copper cable, 2 x 0.25 mmÂ²
Power supply	control voltage: 24 V DC (-15%/+20%); load voltage: according to I/O type
Box supply current	85 mA + current consumption of sensors, max. 0.5 A
Auxiliary power current 1	according to I/O type
Vibration/shock resistance	conforms to EN 60068-2-6/EN 60068-2-27
EMC immunity/emission	conforms to EN 61000-6-2/EN 61000-6-4
Protect. rating/installation pos.	IP65/66/67 (conforms to EN 60529)/variable
Approvals/markings	CE, UL
Housing - Dimensions (W x H x D)	30 mm x 175 mm x 26.5 mm
Housing - Material	PA6 (polyamide)
Housing - Installation	2 fixing holes 3.5 mm diameter for M3
Nominal voltage	24 V DC (-15%/+20%)
Connection technology	M23 connector with outer thread, 12-pin
SSI encoder connection	M23 connector with outer thread, 12-pin
Signal input	difference signal (RS485)
Encoder supply	24 V DC, from load voltage
