IP1002-B310 - Beckhoff Fieldbus Box And IO-Link Box

Name: Beckhoff IP1002-B310
Brand: Beckhoff
SKU: IP1002-B310
Rating: 4.6 (4 reviews)

Technical Specifications of Beckhoff Fieldbus Box And IO-Link Box IP1002-B310:

IP1002-B310 Beckhoff Fieldbus Box And IO-Link Box Technical Specifications

Specification	Value
Input filter	3.0 ms
"0" signal voltage	-3...+5 V (EN 61131-2, type 2)
"1" signal voltage	11...30 V (EN 61131-2, type 2)
Sensor supply	from control voltage, max. 0.5 A, short-circuit proof in total
Power supply connection	feed: 1 x M8 male socket, 4-pin, a-coded; downstream connection: 1 x M8 female socket, 4-pin, a-coded
Bit width in the process image	8 inputs
Electrical isolation	channels/control voltage: no, between the channels: no, control voltage/fieldbus: depends on the bus system
Configuration possibility	via KS2000 or the controller, DP-V1 extensions are supported
Data transfer rates	automatic detection up to 12 Mbaud
Bus interface	1 x M12 socket, 5-pin, B-coded
Data transfer medium	shielded copper cable, 2 x 0.25 mmÂ²
Power supply	control voltage: 24 V DC (-15%/+20%); load voltage: according to I/O type
Box supply current	85 mA + current consumption of sensors, max. 0.5 A
Auxiliary power current 1	according to I/O type
Vibration/shock resistance	conforms to EN 60068-2-6/EN 60068-2-27
EMC immunity/emission	conforms to EN 61000-6-2/EN 61000-6-4
Protect. rating/installation pos.	IP65/66/67 (conforms to EN 60529)/variable
Approvals/markings	CE, UL
Housing - Dimensions (W x H x D)	30 mm x 175 mm x 26.5 mm
Housing - Material	PA6 (polyamide)
Housing - Installation	2 fixing holes 3.5 mm diameter for M3
Number of inputs	8
Input connections	M12, screw type
Nominal input voltage	24 V DC (-15%/+20%)
Input current	typ. 6 mA (EN 61131-2, type 2)
