IE6002 - Beckhoff Extension Box Communication
Technical Specifications of Beckhoff Extension Box Communication IE6002:
| Brand | Beckhoff |
| Product Type | Extension Box Communication |
| Product | IE6002 |
IE6002 Beckhoff Extension Box Communication Technical Specifications
| Specification | Value |
|---|
| "0" signal voltage | -18...+3 V |
| "1" signal voltage | 3...18 V |
| Power supply connection | feed: 1 x M8 male socket, 4-pin, a-coded; downstream connection: 1 x M8 female socket, 4-pin, a-coded |
| Bit width in the process image | input/output: 3 x 8Â bit user data, 1 x 8Â bit control/status (up to 5 x 8Â bit user data are possible) |
| Current consumption from US(without sensor current) | 40 mA |
| Electrical isolation | RS232/control voltage: 500 V, to the fieldbus: yes, via IP-Link |
| Operating temperature | 0...55°C |
| Storage temperature | -25...+85°C |
| Vibration/shock resistance | conforms to EN 60068-2-6/EN 60068-2-27 |
| EMC immunity/emission | conforms to EN 61000-6-2/EN 61000-6-4 |
| Protect. rating/installation pos. | IP65/66/67 (conforms to EN 60529)/variable |
| Approvals/markings | CE, UL |
| Housing - Dimensions (W x H x D) | 30 mm x 126 mm x 26.5 mm |
| Housing - Material | PA6 (polyamide) |
| Housing - Installation | 2 fixing holes 3.5 mm diameter for M3 |
| Nominal voltage | 24 V DC (-15%/+20%) |
