ER8309-1022 - Beckhoff Multi-functional Box
Technical Specifications of Beckhoff Multi-functional Box ER8309-1022:
| Brand | Beckhoff |
| Product Type | Ethernet Box |
| Product | ER8309-1022 |
ER8309-1022 Beckhoff Multi-functional Box Technical Specifications
| Specification | Value |
|---|---|
| Protocol | EtherCAT |
| Bus interface | 2 x M8 socket, 4-pin, a-coded, shielded |
| Input filter | 3 ms |
| Sensor supply | from control voltage US |
| Electrical isolation | 500 V |
| Weight | approx. 450 g |
| Operating temperature | -25...+60°C |
| Storage temperature | -40...+85°C |
| Vibration/shock resistance | conforms to EN 60068-2-6/EN 60068-2-27 |
| EMC immunity/emission | conforms to EN 61000-6-2/EN 61000-6-4 |
| Protect. rating/installation pos. | IP65/66/67 (conforms to EN 60529)/variable |
| Approvals/markings | CE, UL |
| Housing - Dimensions (W x H x D) | 60 mm x 126 mm x 26.5 mm |
| Housing - Material | zinc die-cast |
| Housing - Installation | 2 fixing holes 3.5 mm diameter for M3; 2 fixing holes 4.5 mm diameter for M4 |
| Special features | multi-functional I/O box for universal use |
| Number of channels | 8 digital inputs or outputs (6â¦13) |
| Measurement error/uncertainty | input: < 0.3%, output: < 0.1% (each relative to full scale value) |
| Nominal voltage | 24 V DC (-15%/+20%) |
| Connection method | M12, screw type |
