EPX2004-0022 - Beckhoff EtherCAT Box Digital Output
EPX2004-0022 Beckhoff EtherCAT Box Digital Output Technical Specifications
| Brand | Beckhoff |
| Product Type | EtherCAT Box Digital Output |
| Product | EPX2004-0022 |
EPX2004-0022 Beckhoff EtherCAT Box Digital Output Technical Specifications
| Specification | Value |
|---|---|
| Protocol | EtherCAT |
| Bus interface | 2 x M8 socket, 4-pin, a-coded, shielded |
| Power supply connection | feed: 1 x M8 male socket, 4-pin; downstream connection: 1 x M8 female socket, 4-pin |
| Sensor supply | from load supply voltage UP |
| Current consumption from US | 35 mA |
| Weight | approx. 300 g |
| Operating temperature | -25...+60Β°C |
| Storage temperature | -40...+85Β°C |
| Vibration/shock resistance | conforms to EN 60068-2-6/EN 60068-2-27 |
| EMC immunity/emission | conforms to EN 61000-6-2/EN 61000-6-4 |
| Protect. rating/installation pos. | IP65/66/67 (conforms to EN 60529)/variable |
| Approvals/markings | CE, UL, ATEX, IECEx |
| Housing - Dimensions (W x H x D) | 60 mm x 126 mm x 26.5 mm |
| Housing - Material | PA6 (polyamide) |
| Housing - Installation | 2 fixing holes 3.5 mm diameter for M3; 2 fixing holes 4.5 mm diameter for M4 |
| Load type | ohmic, inductive, capacitive |
| Max. output current | 50 mA per channel |
| Number of outputs | 4 |
| Connection method | 2-wire |
| Open circuit voltage | 24 V DC |
| Output connections | M12 x 1, 5-pin, a-coded |
