EPP3184-0002 - Beckhoff Industrial Housing
Technical Specifications of Beckhoff Industrial Housing EPP3184-0002:
| Brand | Beckhoff |
| Product Type | Industrial Housing |
| Product | EPP3184-0002 |
EPP3184-0002 Beckhoff Industrial Housing Technical Specifications
| Specification | Value |
|---|---|
| Protocol | EtherCAT |
| Bus interface | 2 x M8 socket, P-coded, shielded |
| Number of inputs | 4 (single-ended) |
| Input connections | M12 x 1, 5-pin, a-coded |
| Input filter | configurable |
| Sensor supply | from load supply voltage UP |
| Current consumption from US | typ. 100 mA |
| Operating temperature | -25...+60°C |
| Storage temperature | -40...+85°C |
| Vibration/shock resistance | conforms to EN 60068-2-6/EN 60068-2-27 |
| EMC immunity/emission | conforms to EN 61000-6-2/EN 61000-6-4 |
| Protect. rating/installation pos. | IP65/66/67 (conforms to EN 60529)/variable |
| Approvals/markings | CE, UL |
| Housing - Dimensions (W x H x D) | 30 mm x 126 mm x 26.5 mm |
| Housing - Material | PA6 (polyamide) |
| Housing - Installation | 2 fixing holes 3.5 mm diameter for M3 |
| Special features | current or voltage parameterizable |
| Weight | approx. 165 g |
| Electrical isolation | 500 V |
| Conversion time | ~ 100 µs |
| Resolution | 16 bit (incl. sign) |
| Signal type | -10/0â¦+10 V | 0/4â¦20 mA, parameterizable per channel |
| Common-mode voltage UCM | max. 35 V |
| Internal resistance | > 200 kΩ | typ. 85 Ω + diode voltage |
| Measurement error/uncertainty | < ±0.3% (relative to full scale value) |
| Input filter limit frequency | 5 kHz |
| Nominal voltage | 24 V DC (-15%/+20%) |
