EP7211-0035 - Beckhoff EtherCAT Box Compact Drive Technology
EP7211-0035 Beckhoff EtherCAT Box Compact Drive Technology Technical Specifications
| Brand | Beckhoff |
| Product Type | EtherCAT Box Compact Drive Technology |
| Product | EP7211-0035 |
EP7211-0035 Beckhoff EtherCAT Box Compact Drive Technology Technical Specifications
| Specification | Value |
|---|
| Protocol | EtherCAT |
| Bus interface | 2 x M8 socket, 4-pin, a-coded, shielded |
| Number of inputs | 2 x end position, 1 x feedback, 1 x HWE |
| Power supply connection | feed: 1 x 7/8" plug, 5-pin; downstream connection: 1 x 7/8" socket, 5-pin |
| Current consumption from US | 120 mA |
| Electrical isolation | 500 V |
| Weight | approx. 500 g |
| Operating temperature | -25...+60°C |
| Storage temperature | -40...+85°C |
| Vibration/shock resistance | conforms to EN 60068-2-6/EN 60068-2-27 |
| EMC immunity/emission | conforms to EN 61000-6-2/EN 61000-6-4 |
| Protect. rating/installation pos. | IP65/66/67 (conforms to EN 60529)/variable |
| Approvals/markings | CE, UL, TÃV SÃD |
| Housing - Dimensions (W x H x D) | 60 mm x 150 mm x 26.5 mm |
| Housing - Material | PA6 (polyamide) |
| Housing - Installation | 2 fixing holes 3.5 mm diameter for M3; 2 fixing holes 4.5 mm diameter for M4 |
| Special features | compact and system-integrated, absolute feedback, One Cable Technology (OCT), plug and play, STO (Safe Torque Off), preset drive profile CiA DS402 |
| Number of channels | 1 |
| Load type | permanent magnet-excited three-phase synchronous motor |
| Number of outputs | 1 x servomotor, 1 x motor brake |
| Connection method | direct motor connection with OCT |
