EP6080-0000 - Beckhoff EtherCAT Box Communication
EP6080-0000 Beckhoff EtherCAT Box Communication Technical Specifications
| Brand | Beckhoff |
| Product Type | EtherCAT Box Communication |
| Product | EP6080-0000 |
EP6080-0000 Beckhoff EtherCAT Box Communication Technical Specifications
| Specification | Value |
|---|---|
| Protocol | EtherCAT |
| Bus interface | 2 x M8, shielded |
| Power supply connection | feed: 1 x M8 male socket, 4-pin, a-coded; downstream connection: 1 x M8 female socket, 4-pin, a-coded |
| Current consumption from US | typ. 120 mA |
| Electrical isolation | 500 V |
| Weight | approx. 165 g |
| Operating temperature | -25...+60Β°C |
| Storage temperature | -40...+85Β°C |
| Vibration/shock resistance | conforms to EN 60068-2-6/EN 60068-2-27 |
| EMC immunity/emission | conforms to EN 61000-6-2/EN 61000-6-4 |
| Protect. rating/installation pos. | IP65/67/variable |
| Approvals/markings | CE, UL |
| Housing - Dimensions (W x H x D) | 30 mm x 126 mm x 26.5 mm |
| Housing - Material | PA6 (polyamide) |
| Housing - Installation | 2 fixing holes 3.5 mm diameter for M3 |
| Nominal voltage | 24 V DC (-15%/+20%) |
