EP3754-0702 - Beckhoff EtherCAT Box Analog Input
EP3754-0702 Beckhoff EtherCAT Box Analog Input Technical Specifications
| Brand | Beckhoff |
| Product Type | EtherCAT Box Analog Input |
| Product | EP3754-0702 |
EP3754-0702 Beckhoff EtherCAT Box Analog Input Technical Specifications
| Specification | Value |
|---|---|
| Input filter | configurable |
| Sensor supply | from load supply voltage, max. 0.5 A, short-circuit proof in total |
| Housing - Dimensions (W x H x D) | 30 mm x 155 mm x 26.5 mm |
| Housing - Material | PA6 (polyamide) |
| Housing - Installation | 2 fixing holes 3.5 mm diameter for M3 |
| Measurement error/uncertainty | < ΓΒ±0.3% (relative to full scale value) |
| Conversion time | ~ 100 ΓΒ΅s |
| Signal type | -10/0...+10 V | -20mA/0/4...20 mA, RTD/Pt100/Pt1000, ΓΒ±30/ΓΒ±60/ΓΒ±75 mV (thermocouple), parameterizable per channel |
| Common-mode voltage UCM | 15 V max. |
