EP2624-0002 - Beckhoff EtherCAT Box Digital Output
EP2624-0002 Beckhoff EtherCAT Box Digital Output Technical Specifications
| Brand | Beckhoff |
| Product Type | EtherCAT Box Digital Output |
| Product | EP2624-0002 |
EP2624-0002 Beckhoff EtherCAT Box Digital Output Technical Specifications
| Specification | Value |
|---|---|
| Protocol | EtherCAT |
| Bus interface | 2 x M8 socket, 4-pin, a-coded, shielded |
| Power supply connection | feed: 1 x M8 male socket, 4-pin, a-coded; downstream connection: 1 x M8 female socket, 4-pin, a-coded |
| Current consumption from US | 200ร mA |
| Electrical isolation | 500 V |
| Weight | approx. 165 g |
| Operating temperature | -25...+60ยฐC |
| Storage temperature | -40...+85ยฐC |
| Vibration/shock resistance | conforms to EN 60068-2-6/EN 60068-2-27 |
| EMC immunity/emission | conforms to EN 61000-6-2/EN 61000-6-4 |
| Protect. rating/installation pos. | IP65/66/67 (conforms to EN 60529)/variable |
| Approvals/markings | CE, UL, ATEX, IECEx |
| Ex marking | ATEX:II 3 G Ex ec IIC T4 GcII 3 D Ex tc IIIC T135 รยฐC DcIECEx:Ex ec IIC T4 GcEx tc IIIC T135 รยฐC Dc |
| Housing - Dimensions (W x H x D) | 30 mm x 126 mm x 26.5 mm |
| Housing - Material | PA6 (polyamide) |
| Housing - Installation | 2 fixing holes 3.5 mm diameter for M3 |
| Special features | potential-free switching |
| Load type | ohmic, inductive, lamp load |
| Number of outputs | 4 x make contacts |
| Output connections | M12 x 1, 5-pin, a-coded |
| Nominal output voltage | 25 V AC/30 V DC |
