EP2028-0001 - Beckhoff EtherCAT Box Digital Output
EP2028-0001 Beckhoff EtherCAT Box Digital Output Technical Specifications
| Brand | Beckhoff |
| Product Type | EtherCAT Box Digital Output |
| Product | EP2028-0001 |
EP2028-0001 Beckhoff EtherCAT Box Digital Output Technical Specifications
| Specification | Value |
|---|---|
| Protocol | EtherCAT |
| Bus interface | 2 x M8 socket, 4-pin, a-coded, shielded |
| Power supply connection | feed: 1 x M8 male socket, 4-pin, a-coded; downstream connection: 1 x M8 female socket, 4-pin, a-coded |
| Current consumption from US | 120 mA |
| Electrical isolation | 500 V |
| Weight | approx. 165 g |
| Operating temperature | -25...+60°C |
| Storage temperature | -40...+85°C |
| Vibration/shock resistance | conforms to EN 60068-2-6/EN 60068-2-27 |
| EMC immunity/emission | conforms to EN 61000-6-2/EN 61000-6-4 |
| Protect. rating/installation pos. | IP65/66/67 (conforms to EN 60529)/variable |
| Approvals/markings | CE, UL, ATEX, IECEx |
| Ex marking | ATEX:II 3 G Ex ec IIC T4 GcII 3 D Ex tc IIIC T135 °C DcIECEx:Ex ec IIC T4 GcEx tc IIIC T135 °C Dc |
| Housing - Dimensions (W x H x D) | 30 mm x 126 mm x 26.5 mm |
| Housing - Material | PA6 (polyamide) |
| Housing - Installation | 2 fixing holes 3.5 mm diameter for M3 |
| Load type | ohmic, inductive, lamp load |
| Max. output current | 2 A per channel, individually short-circuit proof, â 4 A |
| Switching times | typ. TON: 200 µs, typ. TOFF: 200 µs |
| Short-circuit current | typ. 15 A |
| Auxiliary power current | typ. 20 mA + load |
| Number of outputs | 8 |
| Output connections | M8 x 1, 3-pin, a-coded |
| Nominal output voltage | 24 V DC (-15%/+20%) |
