ELX9012 - Beckhoff EtherCAT Terminals System
ELX9012 Beckhoff EtherCAT Terminals System Technical Specifications
| Brand | Beckhoff |
| Product Type | EtherCAT Terminals System |
| Product | ELX9012 |
ELX9012 Beckhoff EtherCAT Terminals System Technical Specifications
| Specification | Value |
|---|---|
| Technology | bus end cover |
| Housing width | 8 mm |
| Special features | cover for power and E-bus contacts |
| Weight | 16 g |
| Operating temperature | -25....+60ยฐC |
| Storage temperature | -40....+85ยฐC |
| Approvals/markings | CE, UL, ATEX, IECEx, cFMus |
| Ex marking | ATEX:ร ร II 3G Ex ec IIC T4 GcIECEx:ร ร Ex ec IIC T4 Gc |
| Housing - Connection cross-section AWG | s*: AWG28...14,st*: AWG28...14,f*: AWG26...16 |
| Housing - Stripping length | 8....9 mm |
| Relative humidity | 95%, no condensation |
| EMC immunity/emission | conforms to EN 61000-6-2/EN 61000-6-4 |
| Vibration/shock resistance | conforms to EN 60068-2-6/EN 60068-2-27 |
| Protect. rating/installation pos. | IP20/see documentation |
