EL9561 - Beckhoff EtherCAT Terminals System

Name: Beckhoff EL9561
Brand: Beckhoff
SKU: EL9561
Rating: 4.6 (4 reviews)

EL9561 Beckhoff EtherCAT Terminals System Technical Specifications

Brand	Beckhoff
Product Type	EtherCAT Terminals System
Product	EL9561

EL9561 Beckhoff EtherCAT Terminals System Technical Specifications

Specification	Value
Special features	Constant voltage, 2 output ranges 5/20 V, output current measurement 1%, output voltage measurement 0.5%, max. rate of change 1000 V/sec., galvanic isolation
Weight	approx. 55 g
Operating temperature	0...55°C
Storage temperature	-25...+85°C
Approvals/markings	CE
Electrical isolation	channel/E-bus: functional separation 707 V DC type test
Housing - Design form	compact terminal housing with signal LEDs
Housing - Material	polycarbonate
Housing - Dimensions (W x H x D)	12 mm x 100 mm x 68 mm
Housing - Installation	on 35 mm DIN rail, conforming to EN 60715 with lock
Housing - Side by side mounting by means of	double slot and key connection
Housing - Marking	labeling of the BZxxxx series
Housing - Wiring	solid conductor (s), flexible conductor (st) and ferrule (f): spring actuation by screwdriver
Housing - Connection cross-section	s: 0.08...2.5mm²,st: 0.08...2.5 mm²,f*: 0.14...1.5 mm²
Housing - Connection cross-section AWG	s: AWG28...14,st: AWG28...14,f*: AWG26...16
Housing - Stripping length	8....9 mm
Housing - Current load power contacts	Imax: 10 A
Pluggable wiring	for all ESxxxx terminals
Current consumption E-bus	typ. 80 mA
Diagnostics in the process image	yes
Relative humidity	95%, no condensation
EMC immunity/emission	conforms to EN 61000-6-2/EN 61000-6-4
Vibration/shock resistance	conforms to EN 60068-2-6/EN 60068-2-27
Protect. rating/installation pos.	IP20/see documentation
Number of outputs	1
Input voltage	24Â V DC (-15%/+20%)
Output voltage	2 output ranges: 0.5...5 V; 1...20 V (step-down control)
Output current	max. 2 A, limited by the output power
