EL9190 - Beckhoff EtherCAT Terminals System
Beckhoff EL9190 EtherCAT Terminals System is a compact potential supply terminal built for safe and reliable power distribution in automation networks.
| Brand | Beckhoff |
| Product Type | EtherCAT Terminals System |
| Product | EL9190 |
EL9190 Beckhoff EtherCAT Terminals System Technical Specifications
| Specification | Value |
|---|---|
| Technology | potential supply terminal |
| Housing width | 12ร mm |
| Weight | approx. 50 g |
| Operating temperature | -25....+60ยฐC |
| Storage temperature | -40....+85ยฐC |
| Approvals/markings | CE, UL |
| Current load | รขยยค 10 A |
| Nominal voltage | arbitrary up to 230 V AC/DC |
| Electrical isolation | 500 V (E-bus/field potential) |
| Housing - Design form | compact terminal housing with signal LEDs |
| Housing - Material | polycarbonate |
| Housing - Dimensions (W x H x D) | 12 mm x 100 mm x 68 mm |
| Housing - Installation | on 35 mm DIN rail, conforming to EN 60715 with lock |
| Housing - Side by side mounting by means of | double slot and key connection |
| Housing - Marking | labeling of the BZxxxx series |
| Housing - Wiring | solid conductor (s), flexible conductor (st) and ferrule (f): spring actuation by screwdriver |
| Housing - Connection cross-section | s*: 0.08...2.5mmยฒ,st*: 0.08...2.5 mmยฒ,f*: 0.14...1.5 mmยฒ |
| Housing - Connection cross-section AWG | s*: AWG28...14,st*: AWG28...14,f*: AWG26...16 |
| Housing - Stripping length | 8....9 mm |
| Housing - Current load power contacts | Imax: 10 A |
| PE contact | yes |
| Pluggable wiring | for all ESxxxx terminals |
The Beckhoff EL9190 EtherCAT Terminals System is designed as a potential supply terminal that supports nominal voltages up to 230 V AC/DC. With a housing width of 12 mm and a lightweight build of approximately 50 g, it provides an efficient solution for distributing supply potentials within EtherCAT architectures. The unit ensures electrical isolation of 500 V between the E-bus and field potential, delivering a secure setup for sensitive systems. Its current load capacity of up to 10 A and integrated PE contact further enhance its capability to handle demanding automation requirements reliably.
The EL9190 is built with a robust polycarbonate housing and compact terminal design, making it ideal for DIN rail installation. It is engineered for both solid and flexible conductors, supporting cross-sections from 0.08 mmยฒ to 2.5 mmยฒ. The terminal complies with international safety and EMC standards, carrying approvals including CE and UL. By conforming to strict environmental specifications such as operating within -25ยฐC to +60ยฐC and storage down to -40ยฐC, it ensures long-lasting durability in challenging industrial conditions. These certifications and design features underscore Beckhoffโs reputation for engineering excellence and reliability in automation systems.
In industrial practice, the EL9190 EtherCAT Terminals System is widely used by engineers to extend and distribute supply voltages across EtherCAT I/O stations. Maintenance professionals value its secure electrical isolation and fault protection, while system designers utilize it to create scalable and safe automation architectures. It is particularly suited for power distribution in applications like packaging machinery, machine tools, and process control systems, where stable energy supply is critical for uninterrupted operation. With its compact design, global certifications, and proven safety, the Beckhoff EL9190 stands out as a dependable solution for modern automation infrastructures.
