| Number of inputs | 2 (differential) |
| Max. sampling rate | max. 10 µs/100 ksps (per channel, simultaneously) |
| Measurement error/uncertainty | typ. 85 Ω + diode voltage |
| Input filter limit frequency | 80 kHz |
| Measurement error/uncertainty 2 | < ±0.3% (relative to full scale value) up to 10 Hz input signal |
| Housing - Design form | compact terminal housing with signal LEDs |
| Housing - Material | polycarbonate |
| Housing - Dimensions (W x H x D) | 12Â mm x 100Â mm x 68 mm |
| Housing - Installation | on 35 mm DIN rail, conforming to EN 60715 with lock |
| Housing - Side by side mounting by means of | double slot and key connection |
| Housing - Marking | labeling of the BZxxxx series |
| Housing - Wiring | solid conductor (s), flexible conductor (st) and ferrule (f): spring actuation by screwdriver |
| Housing - Connection cross-section | s*: 0.08..2.5 mm²,st*: 0.08...2.5 mm²,f*: 0.14..1.5 mm² |
| Housing - Connection cross-section AWG | s*: AWG28..14,st*: AWG28..14,f*: AWG26...16 |
| Housing - Stripping length | 8…9 mm |
| Housing - Current load power contacts | Imax: 10 A |
| Power supply | via the E-bus |
| Distributed clocks | yes |
| Distributed clock precision | << 1 µs |
| Common-mode voltage UCM | max. 10 V |
| Conversion time | min. 10 µs |
| Electrical isolation | 500 V (E-bus/signal voltage) |
| Current consumption E-bus | typ. 200 mA |
| Bit width in the process image | input: n x 2 x 16 bit data; optionally 2 x 16 bit cycle counter, 4 byte StartNextLatch time |
| Special features | oversampling |
| Weight | approx. 60 g |
| Operating temperature | -25...+60°C |
| Storage temperature | -40....+85°C |
| Relative humidity | 95%, no condensation |
| Vibration/shock resistance | conforms to EN 60068-2-6/EN 60068-2-27 |
| EMC immunity/emission | conforms to EN 61000-6-2/EN 61000-6-4 |
| Protect. rating/installation pos. | IP20/variable |
| Approvals/markings | CE, CCC, UL, ATEX, IECEx |
| Oversampling factor | n = 1â¦100 selectable |
| Ex marking | ATEX:II 3 G Ex ec IIC T4 GcIECEx:Ex ec IIC T4 Gc |
| Pluggable wiring | for all ESxxxx terminals |
| Signal current | 0â¦20 mA |
| Surge voltage resistance | max. 35 V |
