EL3361 - Beckhoff EtherCAT Terminal Analog Input
Technical Specifications of Beckhoff EtherCAT Terminal Analog Input EL3361:
| Brand | Beckhoff |
| Product Type | EtherCAT Terminal Analog Input |
| Product | EL3361 |
EL3361 Beckhoff EtherCAT Terminal Analog Input Technical Specifications
| Specification | Value |
|---|---|
| Number of inputs | 2, for 1 resistor bridge in full bridge technology |
| Function | resistance bridge, strain gauge (SG), voltage measurement |
| Wiring | 4-wire, 6-wire |
| Ground reference (input) | differential |
| Max. sampling rate | 10 kSps |
| Sampling type | simultaneous |
| Measurement error/uncertainty | > 1 Mรยฉ |
| Measuring range, nominal | Uref: รยฑ12 V | UD: รยฑ4 V |
| Measuring range, technical | Uref: รยฑ12,84 V | UD: รยฑ4,28 V |
| Measurement error/uncertainty 2 | < รยฑ0.05% |
| Electrical isolation channel/channel | no |
| Housing - Design form | HD (High Density) housing with signal LEDs |
| Housing - Material | polycarbonate |
| Housing - Dimensions (W x H x D) | 12ร mm x 100ร mm x 68 mm |
| Housing - Installation | on 35 mm DIN rail, conforming to EN 60715 with lock |
| Housing - Side by side mounting by means of | double slot and key connection |
| Housing - Marking | labeling of the BZxxxx series |
| Housing - Wiring | solid conductors (s): direct plug-in technique; fine-stranded conductors (st) and ferrule (f): spring actuation by screwdriver |
| Housing - Connection cross-section | s*: 0.08..2.5 mmยฒ,st*: 0.08...2.5 mmยฒ,f*: 0.14..1.5 mmยฒ |
| Housing - Connection cross-section AWG | s*: AWG28..14,st*: AWG28..14,f*: AWG26...16 |
| Housing - Stripping length | 8โฆ9 mm |
| Housing - Current load power contacts | Imax: 10 A |
| Operating temperature | 0....55ยฐC |
