EL3008-0003 - Beckhoff EtherCAT Terminal Analog Input
Technical Specifications of Beckhoff EtherCAT Terminal Analog Input EL3008-0003:
| Brand | Beckhoff |
| Product Type | EtherCAT Terminal Analog Input |
| Product | EL3008-0003 |
EL3008-0003 Beckhoff EtherCAT Terminal Analog Input Technical Specifications
| Specification | Value |
|---|
| Number of inputs | 8 |
| Function | voltage measurement |
| Wiring | 2-wire |
| Ground reference (input) | cascaded channels |
| Max. sampling rate | min. 2 ms (max. 500 sps) per channel |
| Sampling type | multiplex |
| Measurement error/uncertainty | > 8 MΩ |
| Input filter limit frequency | 1.5 kHz |
| Rise time | typ. 2 ms |
| Dielectric strength | ±25 V per channel to AGND |
| Measuring range, nominal | -3â¦+3 V |
| Measuring range, technical | -3.22â¦+3.22 V |
| Measurement error/uncertainty 2 | < ±0.1% (at 25°C ±5°C, otherwise < ±0.2%) |
| Housing - Design form | compact terminal housing with signal LEDs |
| Housing - Material | polycarbonate |
| Housing - Dimensions (W x H x D) | 24 mm x 100 mm x 52 mm |
| Housing - Installation | on 35 mm DIN rail, conforming to EN 60715 with lock |
| Housing - Side by side mounting by means of | double slot and key connection |
| Housing - Marking | â |
| Housing - Wiring | specific push-in connection |
