| Connection technology | flat-ribbon cable |
| Nominal voltage | 24 V DC (-15%/+20%) |
| “0” signal voltage | -3...+5 V (EN 61131-2, type 1/3) |
| “1” signal voltage | 11...30 V (EN 61131-2, type 3) |
| Input current | typ. 3 mA (EN 61131-2, type 3) |
| Input filter | typ. 3.0 ms |
| Current consumption power contacts | 20Â mA from the 24 V supply (no power contacts) |
| Current consumption E-bus | typ. 100 mA |
| Electrical isolation | 500 V (E-bus/field potential) |
| Special features | combi EtherCAT Terminal, 8 x output 24 V DC, Imax= 0.5Â A, load type: ohmic, inductive, lamp load, reverse voltage protection |
| Weight | approx. 65Â g |
| Operating temperature | 0…55°C |
| Storage temperature | -25…+85°C |
| Relative humidity | 95%, no condensation |
| Vibration/shock resistance | conforms to EN 60068-2-6/EN 60068-2-27 |
| EMC immunity/emission | conforms to EN 61000-6-2/EN 61000-6-4 |
| Protect. rating/installation pos. | IP20/variable |
| Approvals/markings | CE, UL |
| Housing - Design form | compact terminal housing with signal LEDs |
| Housing - Material | polycarbonate |
| Housing - Dimensions (W x H x D) | 12 mm x 100 mm x 73 mm |
| Housing - Installation | on 35 mm DIN rail, conforming to EN 60715 with lock |
| Housing - Side by side mounting by means of | double slot and key connection |
| Housing - Marking | labeling of the BZxxxx series |
| Housing - Wiring | flat-ribbon cable connection |
| Housing - Connection cross-section | common flat-ribbon cables, AWG28, spacing 1.27 mm |
| Housing - Connection cross-section AWG | AWG28 |
| Number of channels | 8 inputs + 8 outputs |
| Load type | ohmic, inductive, lamp load |
| Max. output current | 0.5 A per channel |
| Reverse voltage protection | yes |
| Breaking energy | < 150 mJ/channel |
| Switching times | typ. TON: 60 µs, typ. TOFF: 300 µs |
| Rated current | max. 1 A per connection pin |
