EJ7411 - Beckhoff EtherCAT Plug-in Module
Technical Specifications of Beckhoff EtherCAT Plug-in Module EJ7411:
| Spec | Value |
|---|---|
| Brand | Beckhoff |
| Product Type | EtherCAT Plug-in Module |
| Product | EJ7411 |
🛠️ Get Quotes Instantly from Beckhoff Vendors
🔎 We currently have only one Beckhoff vendors. We’re onboarding more vendors soon. Are you a supplier? Get listed on IndMALL.
EJ7411 Beckhoff EtherCAT Plug-in Module Technical Specifications
| Specification | Value |
|---|---|
| Electrical isolation | 500 V (E-bus/field potential) |
| Weight | approx. 50 g |
| Operating temperature | 0..55°C |
| Storage temperature | -25...+85°C |
| Relative humidity | 95%, no condensation |
| Vibration/shock resistance | conforms to EN 60068-2-6/EN 60068-2-27 |
| EMC immunity/emission | conforms to EN 61000-6-2/EN 61000-6-4 |
| Protect. rating/installation pos. | IP20/see documentation |
| Approvals/markings | CE |
| Housing - Design form | EtherCAT I/O plug-in module |
| Housing - Material | polycarbonate |
| Housing - Installation | on signal distribution board |
| Housing - Mechanical coding | EJ plug-in module: signal-specific coding pins on the housing,signal distribution board: holes in the printed circuit board |
| Housing - Locking | latching lug in circuit board cut-out |
| Housing - Connection method | field wiring: application-specific wiring level on the signal distribution board,EJ plug-in module: 2 x 20-pin socket strip |
| Housing - Dimensions (W x H x D) | 24 mm x 66 mm x 55 mm |
| Current consumption E-bus | typ. 120 mA |
| Number of inputs | 2 x end position, 1 x encoder, 3 x Hall effect sensor |
| Special features | compact and system-integrated |
| Number of channels | 1 |
| Load type | DC motors |
| Number of outputs | 1 x BLDC motor, 1 x motor brake, 1 x sensor supply, 1 x encoder supply |
| Technology | compact drive technology |
| Supply voltage electronics | 24 V DC (via signal distribution board) |
| Supply voltage power | 8â¦48 V DC (via distribution board) |
