CX5630 - Beckhoff Embedded PCs
Beckhoff Embedded PCs CX5630 delivers high-performance industrial control in a compact form, designed for automation, motion control, and demanding computing tasks.
| Brand | Beckhoff |
| Product Type | Embedded PCs |
| Product | CX5630 |
CX5630 Beckhoff Embedded PCs Technical Specifications
| Specification | Value |
|---|---|
| Processor | AMD Ryzen⢠R1505G, 2.0 GHz |
| Number of cores | 2 |
| Flash memory | slot for M.2 SSD (SATA) and microSD card (storage media not included) |
| Main memory | 8 GB DDR4 RAM |
| 1-second UPS | integrated (1 MB on M.2 SSD) |
| Interfaces | 2 x RJ45 10/100/1000 Mbit/s, 1 x DVI-D, 4 x USB 3.0, 1 x optional interface |
| Cooling | passive |
| Diagnostics LED | 1 x power, 1 x TC status, 1 x flash access, 2 x bus status, 2 x user LED |
| Clock | internal battery-backed clock for time and date (battery exchangeable) |
| Operating system | Windows 10 IoT Enterprise 2019 LTSC, Windows 10 IoT Enterprise 2021 LTSC, Windows 11 IoT Enterprise 2024 LTSC, TwinCAT/BSD |
| Control software | TwinCAT 2 runtime TwinCAT 3 runtime (XAR) |
| I/O connection | E-bus or K-bus, automatic recognition |
| Power supply | 24 V DC (-15%/+20%), electrically isolated |
| Max. power consumption | 20 W |
| Max. power consumption E-bus/K-bus | 10 W (5 V/max. 2Â A) |
| Dimensions (W x H x D) | 142 mm x 100Â mm x 92Â mm |
| Weight | approx. 960 g |
| Operating temperature | -25…+60°C |
| Storage temperature | -40…+85°C |
| Relative humidity | 95%, no condensation |
| Vibration/shock resistance | conforms to EN 60068-2-6/EN 60068-2-27 |
| EMC immunity/emission | conforms to EN 61000-6-2/EN 61000-6-4 |
| Protection rating | IP20 |
| Approvals/markings | CE, UL |
| TwinCAT 3 platform level | Performance Plus (50); please see here for an overview of all the TwinCAT 3 platform level |
The Beckhoff CX5630 Embedded PC combines processing power and efficiency with industrial-grade reliability. It is powered by an AMD Ryzen R1505G dual-core 2.0 GHz processor and comes equipped with 8GB DDR4 RAM, ensuring smooth multitasking and control operations. Storage options include an M.2 SSD slot and a microSD slot, supported by an integrated 1-second UPS for data protection. Connectivity features two Gigabit Ethernet ports, DVI-D output, and four USB 3.0 ports, with an additional interface available for expansion. Its passive cooling system improves durability, while the 24V DC electrically isolated power supply ensures stable performance with low energy consumption of just 20W. Designed for industrial resilience, it meets EN vibration and shock standards, supports operation from -25°C to +60°C, and includes IP20 protection. The system is also CE and UL certified, aligning with global compliance needs for industrial automation.
In real-world use, the CX5630 Beckhoff Embedded PC is widely applied in machine automation, process monitoring, building control, and distributed I/O systems. Its compact dimensions (142 x 100 x 92 mm) and weight of only 960 g make it suitable for space-constrained control cabinets. Engineers benefit from its compatibility with TwinCAT 2/3 runtimes for PLC, motion, and communication tasks, while maintenance teams value the long-term reliability enabled by passive cooling and built-in diagnostics LEDs. The device’s scalability ensures it can handle both basic control and more demanding applications, making it an ideal choice for industrial buyers seeking dependable performance. With its balance of processing capability, energy efficiency, and Beckhoff’s trusted engineering, the CX5630 Embedded PC stands out as a robust solution for modern automation challenges.
