CX2062 - Beckhoff Embedded PCs
CX2062 is a high-performance Embedded PC from Beckhoff, designed for complex automation systems that demand robust processing and high-speed data handling. The CX2062 Embedded PC is ideal for machine builders and control engineers managing advanced industrial applications.
| Brand | Beckhoff |
| Product Type | Embedded PCs |
| Product | CX2062 |
CX2062 Beckhoff Embedded PCs Technical Specifications
| Specification | Value |
|---|---|
| Processor | Intel ® Xeon ® D-1548 2.0 GHz |
| Number of cores | 8 |
| Flash memory | slot for CFast card, card not included |
| Main memory | 8 GB DDR4 RAM (expandable ex factory to 64 GB) |
| NOVRAM | 128 kB |
| Interfaces | 2 x RJ45 10/100/1000 Mbit/s, 1 x DVI-I, 4 x USB 3.0, 1 x optional interface |
| Cooling | integrated fan with ball bearings and speed monitoring |
| Diagnostics LED | 1 x power, 1 x TC status, 1 x flash access, 2 x bus status |
| Clock | internal battery-backed clock for time and date (battery exchangeable) |
| Operating system | Windows 10 IoT Enterprise 2016 LTSB, Windows 10 IoT Enterprise 2019 LTSC, Windows 10 IoT Enterprise 2021 LTSC, TwinCAT/BSD |
| Control software | TwinCAT 3 runtime (XAR) |
| I/O connection | via power supply module (E-bus or K-bus, automatic recognition) |
| Power supply | 24 V DC (-15%/+20%) |
| Max. power consumption | 103 W |
| Dimensions (W x H x D) | 204Â mm x 99Â mm x 91Â mm |
| Weight | approx. 1650 g |
| Operating temperature | -25…+60°C |
| Storage temperature | -40…+85°C |
| Relative humidity | 95%, no condensation |
| Vibration/shock resistance | conforms to EN 60068-2-6/EN 60068-2-27 |
| EMC immunity/emission | conforms to EN 61000-6-2/EN 61000-6-4 |
| Protection rating | IP20 |
| Approvals/markings | CE, UL |
| TwinCAT 3 platform level | Very High Performance (80); please see here for an overview of all the TwinCAT 3 platform level |
CX2062 by Beckhoff stands at the top of the Embedded PC portfolio, delivering enterprise-grade processing capabilities for real-time industrial control. Equipped with an Intel® Xeon® D-1548 processor running at 2.0 GHz and featuring 8 cores, this model supports high-speed multitasking across automation, motion, and vision systems. It includes 8 GB DDR4 RAM (expandable up to 64 GB ex-factory) and a CFast card slot for storage-intensive applications, supported by 128 kB NOVRAM to ensure safe data retention during power failures.
Designed for the highest level of performance, the CX2062 Embedded PC runs TwinCAT 3 runtime (XAR) and supports operating systems like Windows 10 IoT Enterprise (2016, 2019, 2021 LTSC) and TwinCAT/BSD. With 2 x Gigabit Ethernet ports, 4 x USB 3.0 ports, a DVI-I interface, and an optional expansion interface, it offers comprehensive connectivity for demanding control environments. The unit features an integrated fan with ball bearings and speed monitoring to manage heat efficiently under full computational loads.
Measuring 204 mm x 99 mm x 91 mm and weighing around 1650 g, the CX2062 fits securely into industrial cabinets and operates reliably in ambient conditions from -25°C to +60°C. The 24 V DC power input ensures consistent operation, with maximum power consumption rated at 103 W. It supports E-bus or K-bus I/O via power supply modules and is fully compliant with EN 60068-2-6 and EN 60068-2-27 for vibration/shock, and EN 61000-6-2/6-4 for EMC. The Beckhoff CX2062 Embedded PC is CE and UL certified, positioned at the Very High Performance level within the TwinCAT 3 platform, and trusted for use in complex machinery, plant automation, and high-speed production lines. Visit the official page to learn more: Beckhoff CX2062 Embedded PCs.
