CX2043 - Beckhoff Embedded PCs
CX2043 is a high-end Embedded PC developed by Beckhoff, built for performance-intensive automation environments. The CX2043 Embedded PC is ideal for applications requiring real-time control, advanced processing power, and scalable I/O in industrial systems.
| Brand | Beckhoff |
| Product Type | Embedded PCs |
| Product | CX2043 |
CX2043 Beckhoff Embedded PCs Technical Specifications
| Specification | Value |
|---|---|
| Processor | AMD Ryzen⢠V1807B 3.35 GHz |
| Number of cores | 4 |
| Flash memory | slot for CFast card, card not included |
| Main memory | 8 GB DDR4 RAM (expandable ex factory to 32 GB) |
| NOVRAM | 128 kB |
| Interfaces | 2 x RJ45 10/100/1000 Mbit/s, 1 x DVI-D, 4 x USB 3.2 Gen. 2, 1 x optional interface |
| Cooling | integrated fan with ball bearings and speed monitoring |
| Diagnostics LED | 1 x power, 1 x TC status, 1 x flash access, 2 x bus status |
| Clock | internal battery-backed clock for time and date (battery exchangeable) |
| Operating system | Windows 10 IoT Enterprise 2019 LTSC, Windows 10 IoT Enterprise 2021 LTSC, Windows 11 IoT Enterprise 2024 LTSC, TwinCAT/BSD |
| Control software | TwinCAT 2 runtime TwinCAT 3 runtime (XAR) |
| I/O connection | via power supply module (E-bus or K-bus, automatic recognition) |
| Power supply | 24 V DC (-15%/+20%) |
| Max. power consumption | 70 W |
| Dimensions (W x H x D) | 144Â mm x 99Â mm x 91Â mm |
| Weight | approx. 1230 g |
| Operating temperature | -25…+60°C |
| Storage temperature | -40…+85°C |
| Relative humidity | 95%, no condensation |
| Vibration/shock resistance | conforms to EN 60068-2-6/EN 60068-2-27 |
| EMC immunity/emission | conforms to EN 61000-6-2/EN 61000-6-4 |
| Protection rating | IP20 |
| Approvals/markings | CE, UL |
| TwinCAT 3 platform level | Mid Performance (60); please see here for an overview of all the TwinCAT 3 platform level |
CX2043 by Beckhoff is a powerful Embedded PC featuring a quad-core AMD Ryzen™ V1807B processor running at 3.35 GHz, making it a top choice for automation engineers working on high-demand control and motion systems. It includes 8 GB DDR4 RAM (expandable up to 32 GB ex-factory), a CFast card slot for high-speed storage, and 128 kB NOVRAM for non-volatile data retention in case of sudden power loss.
The CX2043 Embedded PC supports both TwinCAT 2 and TwinCAT 3 runtime (XAR), and is compatible with modern operating systems like Windows 10 IoT Enterprise and Windows 11 IoT Enterprise, as well as TwinCAT/BSD. It offers versatile connectivity options including 2 x Gigabit Ethernet ports, 4 x USB 3.2 Gen. 2 ports, 1 x DVI-D display output, and an optional interface for expansion. Its integrated fan with ball bearings and speed monitoring ensures thermal stability even under full load conditions.
Designed for tough industrial environments, the CX2043 operates in temperatures from -25°C to +60°C, features an IP20-rated housing, and conforms to EN 60068-2-6 and EN 60068-2-27 standards for vibration and shock resistance. The system draws 24 V DC input power and has a maximum power consumption of 70 W. With automatic E-bus or K-bus I/O recognition via its power supply module, installation is streamlined for modular applications. The Beckhoff CX2043 Embedded PC carries CE and UL certifications and is trusted in sectors like machine building, process automation, and advanced robotics. For complete details, visit the official product page: Beckhoff CX2043 Embedded PCs.
