CU2005 - Beckhoff EtherCAT Switches And Components
CU2005 Beckhoff EtherCAT Switches And Components Technical Specifications
| Brand | Beckhoff |
| Product Type | EtherCAT Switches And Components |
| Product | CU2005 |
CU2005 Beckhoff EtherCAT Switches And Components Technical Specifications
| Specification | Value |
|---|---|
| Data transfer rates | 10/100 MBit/s, IEEE 802.3u auto-negotiation, half or full duplex, automatic settings |
| Power supply | 24 (18Γ’ΒΒ¦30) V DC, 3-pin connection (+, -, PE) |
| Operating temperature | 0...55Β°C |
| Storage temperature | -25...+85Β°C |
| Protect. rating/installation pos. | IP20/variable |
| Approvals/markings | CE, UL |
| Weight | approx. 260 g |
| Housing - Dimensions (W x H x D) | 73 mm x 100 mm x 30 mm |
| Housing - Material | V2a stainless steel/aluminum |
| Housing - Installation | on 35 mm DIN rail, conforming to EN 60715 with lock |
| Bus system | all Ethernet (IEEE 802.3)-based protocols, store and forward switching mode, unmanaged |
| Number of Ethernet ports | 5 |
| Ethernet interface | 10BASE-T/100BASE-TX Ethernet, RJ45 |
| Cable length | up to 100 m twisted pair |
| Hardware diagnostics | 2 LEDs per channel, activity, link |
| Current consumption | typ. 90 mA |
