CP62xx-xxxx-0090 - Beckhoff Single Touch Panel PCs
CP62xx-xxxx-0090 Beckhoff Single Touch Panel PCs Technical Specifications
| Brand | Beckhoff |
| Product Type | Single Touch Panel PCs |
| Product | CP62xx-xxxx-0090 |
CP62xx-xxxx-0090 Beckhoff Single Touch Panel PCs Technical Specifications
| Specification | Value |
|---|---|
| Device type | Economy built-in Panel PC |
| Housing | aluminum front with sheet-steel rear cover |
| Slots for hard disk/flash | 1 slot for 2½-inch hard disk/SSD, 1 slot for CFast |
| Installation | pull-out clamping levers for fast installation without loose parts |
| Protection rating | front side IP65, rear side IP20 |
| Display size/resolution | 12" 800 x 600, 15" 1024 x 768 or 19" 1280 x 1024 |
| Touch screen | single-finger touch screen or touch pad |
| Front keyboard | alphanumerical or numerical PC keyboard in US layout or only function keys, each variant with 10 PLC special keys and LEDs or front laminate without keys, only display |
| Processor | Intel®Celeron®6600HE 2.6 GHz base frequency, 2 cores (TC3: 50) |
| Motherboard | 3½-inch motherboard for 11thgeneration Intel®Celeron®, Core⢠i3/i5/i7 |
| Memory | 4 GB DDR4 RAM |
| Graphic | integrated in the processor |
| Ethernet | 1 x 100/1000/2500BASE-T and 1 x 100/1000BASE-T on-board |
| RAID | on-board SATA RAID 1 controller |
| Hard disks/flash | hard disk, 2½-inch, 320 GB |
| Interfaces | 4 x USB 3.2 Gen. 2, 1 x RS232, 1 x DVI |
| Power supply | 24 V DC |
