C6930-0080 - Beckhoff Compact Industrial PCs
C6930-0080 Beckhoff Compact Industrial PCs Technical Specifications
| Brand | Beckhoff |
| Product Type | Compact Industrial PCs |
| Product | C6930-0080 |
C6930-0080 Beckhoff Compact Industrial PCs Technical Specifications
| Specification | Value |
|---|---|
| Device type | Control cabinet Industrial PC |
| Housing | aluminum housing |
| Installation | mounting sheet at the rear wall |
| Slots for hard disk/flash | 2 slots for 2½-inch hard disk/SSD, 1 slot for CFast |
| Free space for air circulation | 5 cm (2") on top and bottom of the PC required |
| Protection rating | IP20 |
| Operating temperature | 0…55°C |
| Weight of basic configuration | 2.1 kg (4.6 lbs) |
| Dimensions (W x H x D) | 90 x 235 x 121 mm (3.5" x 9.3" x 4.8"), without mounting plate |
| Processor | Intel®Celeron®6600HE 2.6 GHz base frequency, 2 cores (TC3: 50) |
| Motherboard | 3½-inch motherboard for 11thgeneration Intel®Celeron®, Core⢠i3/i5/i7 |
| Memory | 4 GB DDR4 RAM |
| Graphic | integrated in the processor |
| Ethernet | 1 x 100/1000/2500BASE-T and 1 x 100/1000BASE-T on-board |
| RAID | on-board SATA RAID 1 controller |
| Hard disks/flash | hard disk, 2½-inch, 320 GB |
| Interfaces | 4 x USB 3.2 Gen. 2, 1 x RS232, 1 x DVI |
| Power supply | 24 V DC |
