C6017-0030 - Beckhoff Ultra Compact Industrial PCs
Technical Specifications of Beckhoff Ultra Compact Industrial PCs C6017-0030:
| Spec | Value |
|---|
| Brand | Beckhoff |
| Product Type | Ultra Compact Industrial PCs |
| Product | C6017-0030 |
C6017-0030 Beckhoff Ultra Compact Industrial PCs Technical Specifications
| Specification | Value |
|---|
| Device type | Ultra-compact control cabinet PC |
| Housing | aluminum zinc die-cast housing |
| Installation | mounting sheet at the rear wall |
| Slots for hard disk/flash | 1 slot for M.2 SSD |
| Cooling | passive with single side cooling plate |
| Free space for air circulation | 5 cm (2") on top and bottom of the PC required |
| Protection rating | IP20 |
| Operating temperature | 0…50°C |
| Dimensions (W x H x D) | 82 x 82 x 66 mm (3.2" x 3.2" x 2.6"), without mounting plate |
| Processor | Intel Atom®x6214RE, 1.4 GHz, 2 cores (TC3: 40) |
| Motherboard | compact motherboard for Intel Atom®x6 |
| Memory | 4 GB DDR4 RAM |
| Graphic | integrated in the processor |
| Ethernet | 2 x 100/1000/2500BASE-T on-board |
| Hard disks/flash | 40 GB M.2 SSD |
| Interfaces | 2 x USB 3.1 Gen. 2, 1 x DisplayPort |
| Power supply | 24 V DC |
