C5210-0040 - Beckhoff 19-inch Slide-in Industrial PC
C5210-0040 Beckhoff 19-inch Slide-in Industrial PC Technical Specifications
| Brand | Beckhoff |
| Product Type | 19-inch Slide-in Industrial PC |
| Product | C5210-0040 |
C5210-0040 Beckhoff 19-inch Slide-in Industrial PC Technical Specifications
| Specification | Value |
|---|---|
| Device type | 19-inch slide-in Industrial PC |
| Housing | stainless steel based housing, 1 high units, with lockable front flap |
| Front flap | lockable, includes 2 x USB 2.0, reset key and ATX key |
| Slots for hard disk/flash | 2 removable frames for hard disks |
| Protection rating | IP20 |
| Operating temperature | 0…55°C |
| Dimensions (W x H x D) | 482.7 x 44 x 493.8 mm (19" x 1.7" x 19.44"), depth behind front 475 mm (18.7") |
| Processor | Intel®Celeron®G4900 3.1 GHz, 2 cores (TC3: 50) |
| Motherboard | 3½-inch motherboard for 8th/9thgeneration Intel®Celeron®, Pentium®, Core⢠i3/i5/i7 |
| PCIe®/PCI slots | 2 PCIe®module slots to plug-in Beckhoff PCIe®modules or to led out interfaces of the motherboard ex factory |
| Memory | 4 GB DDR4 RAM |
| Graphic | integrated in the processor |
| Ethernet | 2 x 100/1000BASE-T on-board |
| RAID | on-board SATA RAID 1 controller |
| Hard disks/flash | hard disk, 3½-inch, 1 TB |
| Interfaces | 4 x USB 3.1 Gen. 1, 1 x RS232 at the rear, 2 x USB 2.0 behind the front flap, 1 x DVI |
| Power supply | 100…240 V AC |
