ASI8122-ABCC-W3YZ - Beckhoff Servo Drives
ASI8122-ABCC-W3YZ Beckhoff Servo Drives Technical Specifications
| Brand | Beckhoff |
| Product Type | Servo Drives |
| Product | ASI8122-ABCC-W3YZ |
ASI8122-ABCC-W3YZ Beckhoff Servo Drives Technical Specifications
| Specification | Value |
|---|---|
| Rotor moment of inertia | 0.28Γ kgcmΓΒ² |
| Motor feedback | single-turn encoder, magnetic, resolution 16Γ bit |
| System bus | EtherCAT |
| Drive profile | MDP profile, DS402 profile |
| Connection technology | M12, l-coded/M8, screw type, 3-pin, a-coded/M8, screw type, 4-pin, a-coded |
| Ambient temperature (operation) | 5...40Β°C |
| Approvals/markings | CE, cURus in preparation |
| Housing - Protection rating | IP43 |
| Housing - Design form | flange-mounted according to IM B5, IM V1, IM V3 |
| Housing - Material | aluminum |
| Housing - Coating/surface | dark gray powder coating, similar to RAL7016 |
| Nominal voltage | 24Γ’ΒΒ¦48Γ VΓ DC |
