AM8743-WHYZ - Beckhoff Rotary Servomotors
Technical Specifications of Beckhoff Rotary Servomotors AM8743-WHYZ:
| Brand | Beckhoff |
| Product Type | Rotary Servomotors |
| Product | AM8743-WHYZ |
AM8743-WHYZ Beckhoff Rotary Servomotors Technical Specifications
| Specification | Value |
|---|
| Motor type | permanent magnet-excited three-phase synchronous motor |
| Nominal voltage | 100...480 V AC |
| Standstill torque | 5.65 Nm |
| Rated torque | 4.90 Nm |
| Peak torque | 29.25 Nm |
| Rated speed | 5000 min-1 |
| Rated power | 2.57 kW |
| Standstill current | 5.40 A |
| Peak current | 31.00Â A |
| Torque constant | 1.04Â Nm/A |
| Rotor moment of inertia | 2.87 kgcm² |
| Motor feedback | resolver, single-turn absolute encoderOCT, 24Â bit, SIL 2-capable, single-turn or multi-turn absolute encoder, electronic nameplateOCT, 24Â bit, SIL 2-capable, single-turn or multi-turn absolute encoder, electronic nameplate, B/SSD |
| Cooling | convection |
| Connection technology | M23 speedtec®socket or direct connection for AX5000/AX8000 |
| Ambient temperature (operation) | 5..40°C |
| Approvals/markings | CE, cURus in preparation |
| Housing - Protection rating | IP69K not including shaft feedthrough |
| Housing - Design form | flange-mounted according to IM B5, IM V1, IM V3 |
| Housing - Material | aluminum |
| Housing - Coating/surface | anodized |
| Dimensions - a | 80 j6 |
| Dimensions - b | 19 k6 |
| Dimensions - d | 40 mm |
| Dimensions - l | 100 mm |
| Dimensions - r | 114 mm |
| Dimensions - k (without brake) | 201 mm |
| Dimensions - k (with brake) | 248 mm |
