AM8374-WXYZ - Beckhoff Rotary Servomotors
Technical Specifications of Beckhoff Rotary Servomotors AM8374-WXYZ:
| Brand | Beckhoff |
| Product Type | Rotary Servomotors |
| Product | AM8374-WXYZ |
AM8374-WXYZ Beckhoff Rotary Servomotors Technical Specifications
| Specification | Value |
|---|---|
| Motor type | permanent magnet-excited three-phase synchronous motor |
| Nominal voltage | 100...480 V AC |
| Standstill torque | 233 Nm |
| Rated torque | 139 Nm |
| Peak torque | 355 Nm |
| Rated speed | 2500 min-1 |
| Rated power | 36.3 kW |
| Standstill current | 125Â A |
| Peak current | 180 A |
| Torque constant | 1.86Â Nm/A |
| Rotor moment of inertia | 180 kgcm² |
| Motor feedback | resolver, single-turn absolute encoderHIPERFACE®, multi-turn absolute encoder |
| Cooling | water cooling |
| Connection technology | terminal box |
| Ambient temperature (operation) | 5..40°C |
| Approvals/markings | CE, cURus in preparation |
| Housing - Protection rating | IP54, IP65 (shaft seal) |
| Housing - Design form | flange-mounted according to IM B5, IM V1, IM V3 |
| Housing - Material | aluminum |
| Housing - Coating/surface | acrylic powder-coated, dark gray, similar to RAL7016 |
| Dimensions - k (without brake) | 398.5 mm |
| Dimensions - k (with brake) | 459.5Â mm |
