AM8113-WFYZ - Beckhoff Rotary Servomotors
Technical Specifications of Beckhoff Rotary Servomotors AM8113-WFYZ:
| Brand | Beckhoff |
| Product Type | Rotary Servomotors |
| Product | AM8113-WFYZ |
AM8113-WFYZ Beckhoff Rotary Servomotors Technical Specifications
| Specification | Value |
|---|---|
| Motor type | permanent magnet-excited three-phase synchronous motor |
| Nominal voltage | 24..48 V DC |
| Standstill torque | 0.52 Nm |
| Rated torque | 0.50 Nm |
| Peak torque | 2.04 Nm |
| Rated speed | 3000 min-1 |
| Rated power | 0.16 kW |
| Standstill current | 4.8 A |
| Peak current | 18,0 A |
| Torque constant | 0.11 Nm/A |
| Rotor moment of inertia | 0.067 kgcm² |
| Motor feedback | resolver, single-turn absolute encoderOCT, 18Â bit, single-turn or multi-turn absolute encoder, electronic nameplateOCT, 24Â bit, SIL 2-capable, single-turn or multi-turn absolute encoder, electronic nameplate |
| Cooling | convection |
| Connection technology | itec®plug |
| Ambient temperature (operation) | 5..40°C |
| Approvals/markings | CE, cURus |
| Housing - Protection rating | IP54 |
| Housing - Design form | flange-mounted according to IM B5, IM V1, IM V3 |
| Housing - Material | aluminum |
| Housing - Coating/surface | dark gray powder coating, similar to RAL7016 |
| Dimensions - a | 30 h7 |
| Dimensions - b | 8 h7 |
| Dimensions - d | 25 mm |
| Dimensions - l | 46 mm |
| Dimensions - r | 40 mm |
| Dimensions - k (without brake) | 137 mm |
| Dimensions - k (with brake) | 169 mm |
