Baumer VIXG-10M.W.06 Industrial Camera
The Baumer VIXG-10M.W.06 Industrial Camera offers a dynamic range, Global shutter, , and onsemi AR0144CS connection. Manufactured by Baumer under the Baumer Industrial Camera category, this model belongs to the CX Series.
| Brand | Baumer |
| Product Type | Industrial Camera |
| Model Number | VIXG-10M.W.06 |
Baumer VIXG-10M.W.06 Industrial Camera – Technical Specifications
| Specification | Value |
|---|---|
| Sensor | onsemi AR0144CS |
| Mono/Color | Mono |
| Sensor type | 1/4″ CMOS |
| Shutter type | Global shutter |
| Resolution | 1280 × 800 px |
| Pixel size | 3.0 × 3.0 µm |
| Exposure time | 0.0011 … 5 ms |
| Image formats, interface frame rate max. | Full Frame, 1280 × 800 px, max. 50 fps |
| Pixel formats | Mono8 |
| Analog controls | Gain 8x |
| Color models | Mono |
| Basic Functions | Exposure, Gain, Trigger / Exposure Active (Flash), Free Running Mode (Live Image) |
| Auto Functions | Exposure Auto, Focus Auto |
| Acquisition / Interface | Adjustable Framerate, Device Link Throughput Limit |
| Synchronization | free running, trigger |
| Trigger sources | Hardware, Software |
| Trigger delay | 0 … 2 s, tracking and buffering of up to 16 trigger signals |
| Process Synchronization | Trigger Delay, Additional Output Modes (e.g. Trigger Ready) |
| Additional Functions | Integrated temperature sensor, Readable additional information (e.g. sensor information), Light control |
| Data interface | Gigabit Ethernet, Transfer rate 1000 Mbit/s, Connector: 8P8C Modular Jack (RJ45), screwable type |
| Process interface | M12/12-pin, A-coded, male |
| Power supply | via M12/12-pin, A-coded, male |
| Width | 50 mm |
| Height | 53 mm |
| Depth | 50 mm |
| Weight | ≤ 350 g |
| Material | zinc die casting and polycarbonate cover |
| Voltage supply range +Vs | #ERROR! |
| Power consumption | Typ. 5.5 W (1 .2 A max. at 24 V) |
| Flash memory size | 4 GB |
| Operating temperature | 0 … +45 °C |
| Storage temperature | -10 … + 60 °C |
| Humidity | 0 … +85 % (non-condensing) |
| Protection class | IP 67 |
| Lines | 3 input lines with fixed debouncer (21 µs), 3 output lines |
| Output line sources | Off, Alarm, DeviceReady, TriggerReady |
